Aeotec
Smart Switch 6
SKU: AEOEZW096-EU
Quickstart
This is a secure On/Off Power Switch for Europe. To run this device please connect it to your mains power supply. Turn the primary controller of
Z-Wave network into inclusion mode, short press the product's Action button that you can find on the product"s housing.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart
section.
Z-Wave ensures a reliable communication by reconfirming every message ( two-way communication)
and every mains powered node can act as a repeater for other nodes (meshed network) in case the
receiver is not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency
range.
If a device supports secure communication it will communicate with other devices secure as long as
this device provides the same or a higher level of security. Otherwise it will automatically turn into a
lower level of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.

Product Description

Aeotec Smart Switch 6 is a low-cost Z-Wave Switch plug-in module specifically used to enable Z-Wave command and control (on/off) of any plug-in tool. It
can report immediate wattage consumption or kWh energy usage over a period of time. In the event of power failure, non-volatile memory retains all
programmed information relating to the unit's operating status.
Its surface has a Smart RGB LED, which can be used for indicating the output load status or strength of the wireless signal. You can configure its indication
colour according to your favour.
The Smart Switch 6 is also a security Z-wave device and supports Over The Air (OTA) feature for the products firmware upgrade.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You
can do this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is
recommended to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is
inoperable.
Press and hold the Action button that you can find on the product"s housing for 20 seconds and then release.
Safety Warning for Mains Powered Devices
ATTENTION: only authorized technicians under consideration of the country-specific installation guidelines/norms may do works with mains power. Prior to
the assembly of the product, the voltage network has to be switched off and ensured against re-switching.
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs to be added to an existing wireless network to communicate
with the devices of this network. This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave

Advertisement

loading
Need help?

Need help?

Do you have a question about the Smart Switch 6 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeotec Smart Switch 6

  • Page 1: Product Description

    Product Description Aeotec Smart Switch 6 is a low-cost Z-Wave Switch plug-in module specifically used to enable Z-Wave command and control (on/off) of any plug-in tool. It can report immediate wattage consumption or kWh energy usage over a period of time. In the event of power failure, non-volatile memory retains all programmed information relating to the unit’s operating status.
  • Page 2: Configuration Parameters

    This device is capable of receiving a new firmware 'over the air'. The update function needs to be supported by the central controller. Once the controller starts the update process, perform the following action to confirm the firmware update: In the case that you need to firmware update your Smart Switch 6, please refer to this article here: https://aeotec.freshdesk.com/solution/articles/6000134294-smart-switch-6-firmware-v1-03-update...
  • Page 3 IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 ... 255 the value sent in the application shall be the desired value minus 256. For example: To set a parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given as negative values too.
  • Page 4 Size: 1 Byte, Default Value: 50 Setting Description 0 - 100 Brightness level range is 0 to 100%. Parameter 90: Enable/Disable the function of parameter 91 and 92. This parameter is used to Enable/Disable the function of parameter 91 and 92. Size: 1 Byte, Default Value: 1 Setting Description...
  • Page 5 Size: 4 Byte, Default Value: 0 Setting Description Report Instantaneous Voltage Report Instantaneous Current (Amperes) Report Instantaneous Watts Report Accumulated kWh Parameter 110: Reset Parameter 111-113 Size: 1 Byte, Default Value: 0 Setting Description Reset Parameter 111-113 Parameter 111: Set the interval time of sending report. This parameter is used to set the interval time of sending report in Report Group 1.
  • Page 6: Technical Data

    1431655765 Reset the product to default factory setting and be excluded from the Z-wave network. Technical Data Dimensions 58x58x70 mm Weight 121 gr Hardware Platform ZM5101 1220000013049 IP Class IP 20 Voltage 230 V Load 3000 W Device Type On/Off Power Switch Network Operation Always On Slave Z-Wave Version...
  • Page 7 Node Information Frame — is a special wireless message issued by a Z-Wave device to announce its capabilities and functions. (c) 2019 Z-Wave Europe GmbH, Antonstr. 3, 09337 Hohenstein-Ernstthal, Germany, All rights reserved, www.zwave.eu. The template is maintained by Z-Wave Europe GmbH.
