6.2 Bipolar

1) Connect the foot switch to the Bi-polar Foot Switch Inlet located at rear panel.
2) Select the appropriate RF Power [W] by Bi-polar Power Increase or Decrease Switch.
3) Connect the Bi-polar Forceps with Cable.

6.3 Summary

6.3.1 Preparations

1) Check if the electrode for the ESU is sterilized.
2) After checking the main power voltage, connect the power cord to the 'Main Inlet' located at the
rear panel of the equipment.
If there is no ground circuit in the power cord, the equipotential grounding cable must be
connected to the 'Equipotential Grounding'.
3) Patch Neutral plate as closely and firmly to the surgery area as possible and secure as the large
contact area as possible.

6.3.2 Operation Sequence

1) After checking the main power voltage(110/220V), connect the power cord to the main power inlet
located at the rear panel of the equipment.
2) Turn on Power Switch.
3) Press 'Pad Mode Selection Switch' to configure the pad mode you want to use.
(150 Basic is not available for the pad mode selection switch.)
4) Mount Neutral plate to 'Return Electrode Inlet'.
