Basic Operation

3 Basic Operation
3.1

Electronic Data Sheet (EDS)

On EtherNet/IP, the characteristics of a device is stored in an ASCII data file with the suffix EDS.
This file is used by configuration tools etc. when setting up the network configuration. HMS
Industrial Networks supplies a standard (generic) EDS file, which corresponds to the default
settings in the module.
Since the module implements the Parameter Object, it is possible for configuration tools such as
Tockwell Automation RSNetWorx
See also..
• Parameter Object (0Fh), p. 26
3.2

Network Identity

By default, the module uses the following identity settings:
Vendor ID:
Device Type:
Product Code:
Product Name:
Optionally, it is possible to customize the identity of the module by using the Anybus Custom
Modbus function code 70.
See also...
• Identity Object (01h), p. 17
• Anybus Custom Modbus Function Code 70, p. 8
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
™ to automatically generate a suitable EDS-file.
(CIP object)
HMS Industrial Networks approves use of the standard EDS file only under the condition
that it matches the actual implementation and that the identity information remains
unchanged.
005Ah (HMS Industrial Networks)
002Bh (Generic Device)
0037h (Anybus CompactCom 40 EtherNet/IP)
"CompactCom 40 EtherNet/IP(TM)"
(CIP object)
7 (54)
