CIP Objects
6.4

Assembly Object (04h)

Object Description
The Assembly object uses static assemblies and holds the process data sent/received by the host application. It
allows data to and from each object to be sent or received over a single connection.
The terms "input" and "output" are defined from the network's point of view. An input will produce data on
the network and an output will consume data from the network.
See also ....
• Network Data Exchange, p. 10
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max instance Get
Instance 03h Attributes (Heartbeat, Input-Only)
This instance is used as heartbeat for Input-Only connections. The data size of the Heartbeat instance in the
Forward_Open request should be 0 bytes, however other values are also permitted.
# Name Access
3 Data Set
4 Size Get
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Type
Value
UINT
0002h (Object revision)
UINT Maximum instance number
Type
Value/Description
- (The data size of this attribute is zero)
N/A
UINT
0 (Number of bytes in attribute 3)
20 (54)
