CIP Objects
# Name Access
6 Interface
Get/Set
Control
Control Bits
Forced
Interface
Speed
7 Get
Interface Type
8 Interface State Get
9
Admin State Get/Set
10 Interface Label Get
11
Interface Get
Capability
Capability Bits
Speed/Duplex
Options
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Type Value
Struct of:
-
WORD
-
UINT
-
USINT
-
USINT
-
USINT
—
SHORT_STRING
-
Struct of:
-
DWORD
-
Struct of:
-
USINT
Array of Struct of: -
-
UINT
-
USINT
Comments
Interface control bits
Speed at which the interface shall be forced to operate.
Returns 'Object state Conflict' if auto-negotiation is
enabled
See table "Interface State" below.
See table "Interface Type" below.
See table "Admin State" below.
See table "Interface Label" below.
Indication of the capabilities of the interface
Interface capabilities, other than speed/duplex
See table "Interface Capability" below.
Indicates speed/duplex pairs supported in the Interface
Control Attribute
Speed/duplex array count
Speed/duplex array
Interface speed
Interface Duplex Mode
0 = half duplex
1 = full duplex
2 - 255 = Reserved
