Anybus CompactCom B40 Network Manual page 38

CIP Objects
Instance Attributes
# Name Access
1 Interface Get
Speed
2 Get
Interface Flags
3 Get
Physical
Address
4 Get
Interface
Counters
In Octets
In Ucast
Packets
In NUcast
Packets
In Discards
In Errors
In Unknown
Protos
Out Octets
Out Ucast
Packets
Out NUcast
Packets
Out Discards
Out Errors
5 Media Get
Counters
Alignment
Errors
FCS Errors
Single
Collisions
Multiple
Collisions
SQE Test Errors
Deferred
Transmissions
Late Collisions
Excessive
Collisions
MAC Transmit
Errors
Carrier Sense
Errors
Frame Too
Long
MAC Receive
Errors
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Type
Value
UDINT 10 or 100
-
DWORD
Array of 6 USINTs (MAC ID)
Struct of:
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
Struct of:
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT 0
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
UDINT
N/A
Comments
Actual Ethernet interface speed.
See table "Interface Flags" below.
Physical network address, i.e. assigned MAC address.
Octets received on the interface
Unicast packets received on the interface
Nonunicast packets received on the interface
Inbound packets with unknown protocol
Inbound packets that contain errors (does not include In
discards)
Inbound packets with unknown protocol
Octets sent on the interface
Unicast packets sent on the interface
Nonunicast packets sent on the interface
Outbound packets with unknown protocol
Outbound packets that contain errors (does not include
Out discards)
Media specific counters
Frames received that are not an integral number of octets
in length
Frames received that do not pass the FCS check
Successfully transmitted frames that have experienced
exactly one collision
Successfully transmitted frames that have experienced
more than one collision
The number of times the SQE test error message is
generated(Counter not provided with current PHY
interface)
Frames for which the first transmission attempt is delayed
because the medium is busy
The number of times a collision is detected later than 512
bit-times into the transmission of a packet
Frames for which a transmission fails due to excessive
collisions
Frames for which a transmission fails due to an internal
MAC sublayer receive error
The number of times that the carrier sense condition was
lost or never asserted when attempting to transmit a frame
Frames received that exceed the maximum permitted
frame size
Frames for which reception on an interface fails due to an
internal MAC sublayer receive error
36 (54)
SCM-1202-131 1.1 en-US
