CIP Objects
6.6

Parameter Object (0Fh)

Object Description
The Parameter Object provides an interface to the configuration data of the module. It can provide all the
information necessary to define and describe each of the module configuration parameters, as well as a full
description of each parameter, including minimum and maximum values.
Each parameter is represented by one instance. Instance numbers start at 1, and are incremented by one, with
no gaps in the list.
See also ....
• ADI Object (A2h), p. 30
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max instance Get
8 Parameter Get
Class
Descriptor
9 Configuration Get
Assembly
Instance
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
(CIP Object)
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Get_Attributes_All
Get_Enum_String
Type Value
UINT
0001h (Object revision)
UINT
Maximum created instance number = class attribute 3 in the Application Data
Object (see Anybus CompactCom 40 Software Design Guide)
WORD
Default: 0000 0000 0000 1011b
Bit: Contents:
0 Supports parameter instances
1 Supports full attributes
2 Must do non-volatile storage save command
3 Parameters are stored in non-volatile storage
UINT 0000h
