Anybus CompactCom B40 Network Manual page 36

CIP Objects
# Name Access
9 Mcast Config Set
Alloc Control
(reserved)
Num Mcast
Mcast Start
Addr
10 Set
SelectAcd
11 Set
LastConflictDe-
tected
AcdActiviity
RemoteMAC
ArpPdu
13 Set
Encapsulation
inactivity
timeout
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Type Value
Struct of:
USINT 0
USINT 0
UINT -1
-
UDINT
1
Bool
Struct of:
-
USINT
ARRAY of 6 USINT -
-
ARRAY of 28
USINT
UINT 0 - 3600
Comments
IP multicast configuration.
Meaning:
Value:
0:
Use default allocation algorithm to generate
multicast addresses
1: Allocate multicast addresses according to the
values in the "Num Mcast"- and "Mcast Start
Addr"-fields.
Set to zero. Do not change.
Number of multicast addresses to allocate for EtherNet/IP
Starting multicast address from which to begin allocation
Meaning:
Value:
0:
Disable ACD
1:
Enable ACD (Default).
If ACD (address conflict detection) is enabled, bit
6 in attribute #1 will be set if an ACD conflict is
detected. The Network Status LED will also
indicate a detected conflict, see
p. 41 .
ACD Diagnostic parameters Related to the last conflict
detected.
State of ACD activity when last conflict detected.
MAC address of remote node form the ARP PDU
in which a conflict was detected.
Copy of the raw ARP PDU in which a conflict was
detected.
Number of seconds of inactivity before a TCP connection is
closed.
0: Disabled
34 (54)
LED Indications,
SCM-1202-131 1.1 en-US
