Appendix A: LED Indications
A LED Indications
See Anybus CompactCom B40 Modbus Serial User Manual for more information.
A.1

Network Status LED

LED State
Off
Green
Green, flashing
Red
Red, flashing
A.2

Module Status LED

LED State
Off
Green
Green, flashing
Red
Red, flashing
A.3

LINK/Activity LEDs

LED State
Off
Green
Green, flickering
Yellow
Yellow, flickering
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Description
No power or no IP address
Online, one or more connections established (CIP Class 1 or 3)
Online, no connections established
Duplicate IP address, FATAL error
One or more connections timed out (CIP Class 1 or 3)
Description
No power
Controlled by a Scanner in Run state
Not configured, or Scanner in Idle state
Major fault (EXCEPTION-state, FATAL error etc.)
Recoverable fault(s). Module is configured, but stored parameters differ from currently used
parameters.
Description
No link, no activity
Link (100 Mbit/s) established
Activity (100 Mbit/s)
Link (10 Mbit/s) established
Activity (10 Mbit/s)
