Preface
1.4

Document Specific Conventions

• The terms "Anybus" or "module" refers to the Anybus CompactCom module.
• The terms "host" or "host application" refer to the device that hosts the Anybus.
• Hexadecimal values are written in the format NNNNh or 0xNNNN, where NNNN is the
hexadecimal value.
• A byte always consists of 8 bits.
• All dimensions in this document have a tolerance of ±0.10 mm unless otherwise stated.
• Outputs are TTL compliant unless otherwise stated.
• Signals which are "pulled to GND" are connected to GND via a resistor.
• Signals which are "pulled to 3V3" are connected to 3V3 via a resistor.
• Signals which are "tied to GND" are directly connected to GND,
• Signals which are "tied to 3V3" are directly connected to 3V3.
1.4.1 Pin Types
The pin types of the connectors are defined in the table below. The pin type may be different
depending on which mode is used.
Pin type
I
O
I/O
OD
Power
1.5

Trademark Information

Anybus ® is a registered trademark of HMS Industrial Networks.
EtherNet/IP is a trademark of ODVA, Inc.
All other trademarks are the property of their respective holders.
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
Caution
This instruction must be followed to avoid a risk of personal injury.
WARNING
This instruction must be followed to avoid a risk of death or serious injury.
Definition
Input
Output
Input/Output (bidirectional)
Open Drain
Pin connected directly to module power supply, GND or 3V3
