CIP Objects
6.9

ADI Object (A2h)

Object Description
Anybus representation of process data mapped parameters.
See also ..
• Parameter Object (0Fh), p. 26
Supported Services
Class:
Instance:
Class Attributes
# Name Access
1 Revision Get
2 Max Instance Get
3 Number of Get
instances
Anybus ® CompactCom ™ B40 Modbus Serial EtherNet/IP Network Guide
(CIP Object)
Get_Attribute_Single
Get_Attribute_Single
Set_Attribute_Single
Type Value
UINT
0002h (Object revision)
UINT
Equals number of parameters
UINT Equals number of parameters
