CIP Objects
6.5
Connection Manager (06h)
Object Description
This object is used for connection and connectionless communications, including establishing connections
across multiple subnets.
Supported Services
Class:
Instance:
Class Attributes
(No supported class attributes)
Instance Attributes
#
Name
Access
1
Open Requests Set
2
Open Format
Set
Rejects
3
Open Resource
Set
Rejects
4
Set
Open Other
Rejects
5
Close Requests Set
6
Close Format
Set
Rejects
7
Close Other
Set
Rejects
8
Connection
Set
Timeouts
Anybus
®
CompactCom
™
B40 Modbus Serial EtherNet/IP Network Guide
-
Get Attribute All
Get Attribute Single
Set Attribute Single
Large_Forward_Open
Forward_Open
Forward_Close
Type
Value/Description
UINT
Number of Forward_Open service requests received.
UINT
Number of Forward_Open service requests which were rejected due to bad
format.
UINT
Number of Forward_Open service requests which were rejected due to lack of
resources.
UINT
Number of Forward_Open service requests which were rejected for reasons
other than bad format or lack of resources.
UINT
Number of Forward_Close service requests received.
UINT
Number of Forward_Close service requests which were rejected due to bad
format.
UINT
Number of Forward_Close service requests which were rejected for reasons
other than bad format.
UINT
Total number of connection timeouts that have occurred in connections
controlled by this Connection Manager.
22 (54)
SCM-1202-131 1.1 en-US
