4.7.1.

Binary Output Attribute

Table 11 Binary Output Attribute Table
Attribute
* Added shading functions are not supported (The response is "N10").
4.7.2.
Binary Output COS Works
Binary Output and Binary Output points have simple COS.
If the
changes.
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Type
Object Configuration
Bit 0 = COS_enabled (1)
Bit 1 = normal state
Bit 2 = unused
1
Byte
Bit 3 = unused
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused

Bit 7 = unused

Object Status
Bit 0 = reliable (0) / unreliable (1)
Bit 1 = override active (1)
Bit 2 = unused
2
Byte
Bit 3 = unused
Bit 4 = normal (0) / alarm (1) (JCI use only)

Bit 5 = normal (0) / trouble (1) (JCI use only)

Bit 6 = current state

Bit 7 = unused
3
Integer
Minimum On-time (sec) (0-65535)
4
Integer
Minimum Off-time (sec) (0-65535)
5
Integer
Maximum Cycles/Hour
6
Integer
Interstage on delay(sec)(0-65535) (JCI use only)
7
Integer
Interstage off delay(sec)(0-65535) (JCI use only)
COS_enabled
bit is set then COS will be reported whenever the
Contents
- 21 -
E6581540
