4.6.1.

Analog Output Attribute

Table 9 Analog Output Attribute Table
Attribute
* Added shading functions are not supported (The response is "N10").
4.6.2.
Analog Output COS Works
Analog Output and Binary Output points have simple COS.
If the
changes.
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Type
Object Configuration
Bit 0 = COS_enabled (1)
Bit 1 = unused

Bit 2 = unused

1
Byte
Bit 3 = unused
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
Object Status
Bit 0 = reliable (0) / unreliable (1)
Bit 1 = override active (1)
Bit 2 = saturated high (1) (JCI use only)
2
Byte
Bit 3 = saturated low (1) (JCI use only)
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
3
Float
Current Value
4
Float
Low Linear Ranging Parameter (JCI use only)
5
Float
High Linear Ranging Parameter (JCI use only)
COS_enabled
bit is set then COS will be reported whenever the
