Toshiba PCT001Z-E Instruction Manual

Trace tool.
Hide thumbs

Advertisement

TOSVERT VF-AS1/PS1
Trace Tool PCT001Z-E
Instruction Manual
1. . . . Be sure to read this manual carefully before connecting and using
the trace tool for the VF-AS1/PS1.
After reading the manual, be sure to store it.
2. . . . The contents of this manual are subject to change without prior
notice.
Notes
E6581478

Advertisement

   Related Manuals for Toshiba PCT001Z-E

   Summary of Contents for Toshiba PCT001Z-E

  • Page 1

    E6581478 TOSVERT VF-AS1/PS1 Trace Tool PCT001Z-E Instruction Manual Notes 1. . . . Be sure to read this manual carefully before connecting and using the trace tool for the VF-AS1/PS1. After reading the manual, be sure to store it. 2. . . . The contents of this manual are subject to change without prior...

  • Page 2

    E6581478 - Contents - Introduction ..........................1 How to use PCT001Z-E......................3 2.1. E ......................3 NABLING MACROS 2.2. L ......................3 ICENSE AGREEMENT 2.3. O ......................4 PENING WINDOW 2.4. S ........................5 ETTING SHEET 2.5. G ........................ 10 RAPHIC SHEET 2.6.

  • Page 3: Introduction

    Displaying read trace data in graphic form Storing trace data *1 PCT001Z-E does not support any inverters other than VF-AS1/PS1. *2 To use PCT001Z-E, the USB converters unit shown in Fig. 1 below are required. ○ USB converters unit (part in this figure) ○...

  • Page 4

    It is recommendable to use a mouse or a similar pointing device for operation. *4 PCT001Z-E may not run normally on some types of PC-98 series computers. *5 It has been confirmed that PCT001Z-E runs normally on the software listed in the table below.

  • Page 5: How To Use Pct001z-e

    Fig. 2 Security warning 2.2.License agreement When PCT001Z-E is started for the first time or after macros have been enabled, the PCT001Z-E license agreement window (Fig. 3) appears. Read the contents carefully and click [agree] if you wish to use PCT001Z-E. Clicking [don’t agree] closes the Excel book.

  • Page 6: O Pening Window

    E6581478 2.3.Opening window When macros are executed, the Opening sheet (Fig. 4) appears. After reading the instruction manual (this manual) carefully, click [To setting >] in the top-right of the window and make necessary settings. Fig. 4 Opening window ① [To setting >] Click this button to move from the Opening sheet to the Setting sheet.

  • Page 7: S Etting Sheet

    'Parity': Specify the parity (F801) of the inverter. 'Inverter number': Specify the number (F802) assigned to the inverter. Since PCT001Z-E uses the Toshiba inverter protocol ASCII mode, only a number between 0 and 99 can be assigned to an inverter.

  • Page 8

    E6581478 Table 1 Table of settings for communications with inverter Default Title Content Adjustment range setting COM port 1~30 F800 Baud rate 0:9600bps 1:19200bps 2:38400bps F801 Parity 0:Non parity 1:Even parity 2:Odd parity F802 Inverter number 0~99 ③ Parameter concerning trace function Fig.

  • Page 9

    E6581478 Table2 Parameter concerning trace functions Default Title Content Adjustment range setting Constant at the F678 4ms~100ms time of filtering F740 Trace selection 0:Deselect 1:At tripping 2:At triggering F741 Trace cycle 0:4ms 1:20ms 2:100ms 3:1s 4:10s 00:Output frequency (Hz) 01:Frequency command value (Hz) 02:Output current (%) 03:Input voltage (%) 04:Output voltage (%)

  • Page 10

    E6581478 ④ Inverter individual information Fig. 8 Inverter individual information 'Inverter form': Displays the type of the inverter. 'Serial number': Displays the serial number of the inverter. 'CPU1 Ver': Displays the version of the inverter’s CPU1. 'CPU2 Ver': Displays the version of the inverter’s CPU2. 'Inverter operating time': Displays the operating time of the inverter.

  • Page 11

    E6581478 ⑩ [The constant at the time of filtering is arbitrarily set.] If this radio button is checked, clicking [Parameter export] will write the value of constant at the time of filtering you have selected from the drop-down menu into the inverter. *6 If you select [Recommended value of constant at the time of filtering is set by the automatic set up.] and [The constant at the time of filtering is arbitrarily set.] to write the set values, the message “Export completion.

  • Page 12: G Raphic Sheet

    E6581478 2.5.Graphic sheet The Graphic sheet (Fig. 10) allows you to read trace data and display it in graphic form. Fig. 10 Graphic sheet Fig. 11 Reset approval...

  • Page 13

    E6581478 ⑪ [Trace data reading] Click this button to read trace data stored in the inverter and display it in graphic form. If the inverter is tripped or “at the time of trigger” is not selected for trace selection, the “Reset approval”...

  • Page 14: D Ata Sheet

    E6581478 2.6.Data sheet The data sheet (Fig. 12) lists 4 kinds of acquired numerical data (data 1 through 4) in groups of 100 each. Fig. 12 Data sheet ⑲ [Trace data save] Click this button to name and save the file automatically. The file name consists of date and time when data is saved.

  • Page 15

    E6581478 ⑳'Time(s)' Displays the time at the same intervals as the trace cycle. “4 kinds of data acquired” Displays 4 kinds of data acquired in groups of 100 each. [< To graph] Click this button to move from the Data sheet to the Graphic sheet. [To setting] Click this button to move from the Data sheet to the Setting sheet.

  • Page 16: Troubleshooting

    (F802), but only a number of up to 99 can be assigned with PCT001Z-E. A5 : Since PCT001Z uses the Toshiba inverter protocol ASCII mode, only a number between 0 and 99 can be assigned to an inverter.
