AN5105
Layout and PCB
Figure 17.
Track routing
Figure 18.
Track routing recommendation
At least 2 mm (4 - 5 mm is recommended)
At least
Ground plane or
twice the
ground track
Any application track
track width
(LED, power, Com.)
As thin as
At least twice the
PCB
panel thickness
technology
allows
Touchkey bank 2
Touchkey bank 1
AN5105 - Rev 1
page 18/52
