Mikroe Codegrip User Manual page 34

WiFi Mode tab
This tab contains some specific WiFi settings for each of the two available
modes of operation. There are two subsections labeled as Access Point
Mode and Station Mode. WiFi settings are grouped into these subsections,
according to the mode they are used for.
Access Point Mode subsection
SSID
This is the wireless network identifier, up to 32 characters long.
Password
The network password can be set in this field. If the security protocol is not
set to Open, the WiFi client is required to provide a password that matches
the string in this field.
Secure type
Options: Open, WEP, WPA/WPA2
The Security protocol of the wireless network can be selected from this
dropdown menu.
Country Code
Options: EU, USA
This option is used to set Tx signal levels and available frequency channels
for the selected region (EU: 1 - 13, USA: 1 - 11).
If used outside of these regions, please set up the WiFi signal parameters
manually (Channel and Tx level), according to your local radio-frequency
regulations.
Channel
Options: 1 to 13
This option is used to select the WiFi radio-frequency band, in relation
with the Country Code settings.
When used in the Access Point (AP) mode, the CODEGRIP device will
have a fixed IP address (192.168.1.1), with the DHCP protocol enabled.
N O T E
C O D E G R I P U S E R M A N U A L
