A D V E N T U R E R I D G E P L AY S E T - F 2 5 7 3 0 E X
INSTALLATION AND OPERATING INSTRUCTIONS
6.3m
10.3m
10 - 12 Hrs
10 - 12 Hrs
Approx. 2 Hrs
2-4 Hrs
FOR FORT & SWING
FOR FORT & SWING
TUBE SLIDE
TWO PERSON
ASSEMBLY
By
Rev 09/06/2018
WARNING
OBSTACLE FREE SAFETY ZONE -33'2" x 30'10" (10.3 x 9.4 m) area requires Protective Surfacing. See page 3.
9.4m
5.4m
MAXIMUM VERTICAL FALL HEIGHT - 6' 7" (2.01 m)
CAPACITY - 15 Users Maximum, Ages 3 to 10; Weight Limit 110 lbs. (49.9 kg) per child.
RESIDENTIAL HOME USE ONLY. Not intended for public areas such as multi-unit residences, schools,
churches, nurseries, day cares or parks.
Warning. Only for domestic use.
Cedar Summit by KidKraft
4630 Olin Road
Dallas, TX 75244, United States
customersupport@kidkraft.com
Online Parts Replacement:
Cedarsummitplay.com/parts-center-warranty-claim
Customer Service:
1(800) 933-0771 or (972) 385-0100
KidKraft Netherlands BV
Olympisch Stadion 29
1076DE Amsterdam, The Netherlands
Europe Customer Service: +31 (0)20 305 8620
europecustomerservice@kidkraft.com
EU Online Parts Replacement: parts.kidkraft.eu
To reduce the risk of serious injury or death, you must
read and follow these instructions. Keep and refer to these
instructions often and give them to any future owner of this
play set. Manufacturer contact information provided below.

Table of Contents

Warnings And Safe Play Instructions . . . . . . . . . . . . . pg. 2
Protective Surfacing Guidelines. . . . . . . . . . . . . . . . . . pg. 3
Instructions For Proper Maintenance . . . . . . . . . . . . pg. 4
About Our Wood – Limited Warranty . . . . . . . . . . . .pg. 5
Keys To Assembly Success . . . . . . . . . . . . . . . . . . . . . . . pg. 6
Part ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 8
Step-By-Step Instructions . . . . . . . . . . . . . . . . . . . . . pg. 19
Installation of I.D./Warning Plaque . . . . . . . . .Final Step
10 - 12 Hrs
FOR FORT & SWING
TWO PERSON
ASSEMBLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cedar Summit Adventure Ridge Playset and is the answer not in the manual?

Questions and answers

Summary of Contents for KidKraft Cedar Summit Adventure Ridge Playset

  • Page 1 Step-By-Step Instructions ..... pg. 19 Europe Customer Service: +31 (0)20 305 8620 Installation of I.D./Warning Plaque ..Final Step europecustomerservice@kidkraft.com Rev 09/06/2018 EU Online Parts Replacement: parts.kidkraft.eu...
  • Page 2 Warnings and Safe Play Instructions CONTINUOUS ADULT SUPERVISION REQUIRED. Most serious injuries and deaths on playground equipment have occurred while children were unsupervised! Our products are designed to meet mandatory and voluntary safety standards. Complying with all warnings and recommendations in these instructions will reduce the risk of serious or fatal injury to children using this play system.
  • Page 3 Protective Surfacing - Reducing Risk of Serious Head Injury From Falls. One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM F1292.
  • Page 4 Instructions for Proper Maintenance Your Cedar Summit Play System is designed and constructed of quality materials with your child’s safety in mind. As with all outdoor products used by children, it will weather and wear. To maximize the enjoyment, safety and life of your Play Set, it is important that you, the owner, properly maintain it.
  • Page 5 Such use may lead to product failure and potential injury. Any and all public use will void this warranty. Cedar Summit by KidKraft disclaims all other representations and warranties of any kind, express or implied province to province. This warranty excludes all consequential damages, however, some states do not allow the...
  • Page 6 Keys to Assembly Success Tools Required Tape Measure 1, 3 Phillips or Robertson Open End Wrench 3/16 Hex Key Carpenters evel bit or Screwdriver (1/2 , /16 /16 ) ’ Step adder Carpenters Square Ratchet(1/2 , /16 Adjustable Wrench Safety Glasses Claw Hammer 9/16”...
  • Page 7 Your Key To Quick Assembly SORTING WOOD PARTS INTO EACH ASSEMBLY STEP WILL SAVE TIME! Step Step Step SAVE TIME - TIP #1: Open each box with wood parts and look for the Key Number stamped on the end of the wood part (see chart below). Sort each wood part into the different assembly steps.
  • Page 9 0 91 0 90...
  • Page 10 Part Identification (Reduced Size) (2) 102 - 5/8 x 1-1/4 x 33-7/8" - Side Rope Trim - Box 2 - 3609174 (1) 105 - 5/8 x 2 x 21-49/64" - Top Front Rope - Box 2 - 3609171 (1) 104 - 5/8 x 3-5/8 x 34" - Right Rope - Box 2 - 3609173 (1) 103 - 5/8 x 2-25/64 x 34"...
  • Page 11 Part Identification (Reduced Size) (16) 346 - 1 x 5 x 16-7/8" - Floor Board - Box 4 - 3599092 (1) 345 - 1 x 5 x 16-7/8" - Floor Board nd A - Box 2 - 3599184 (2) 651 - 1 x 5 x 14-1/2" - Transom Board A - Box 2 - 3599115 (2) 652 - 1 x 5 x 10"...
  • Page 12 Part Identification (Reduced Size) (6) 341 - 1-1/8 x 15-7/8" - Dowel - Tennon - Box 4 - 3681578 (4) 351 - 1-1/8" x 18-5/8" - Dowel - Tennon - Box 4 - 3681858 (2) 205 - 1-1/4 x 2 x 27-1/2" - Crowsnest Spacer - Box 2 - 3599043 (4) 501 - 1 33 - Roof Support - Box 2 - 3599105 (2) 502 - 1-1/4 x 2-1/4 x 29-11/16"...
  • Page 13 Part Identification (Reduced Size) (1) 396 - 1-3/8 x 4-1/2 x 16-47/64" - Tunnel Rail - Box 4 - 3599187 (2) 394 - 1-3/8 x 4-1/2 x 18-3/4" - Safet Rail - Box 4 - 3592922 (2) 371 - 1-3/8 x 3-3/8 x 33" - Access Upright - Box 4 - 3592917 (2) 354 - 1-3/8 x 2-1/2 x 53"...
  • Page 14 Part Identification (Reduced Size) (1) 022 - 1-1/4 x 37 x 92" (1) 031 - 1-1/4 x 43 x 92" (1) 032 - 1-1/4 x 37 x 92" Slide nd Panel Panel Front Wall SW Wall Panel Box 3 - 37598981 Box 3 - 37599007 Box 2 - 37599135 (1) 121 - 1-1/4 x 15-3/4 x 42-1/8"...
  • Page 15 Part Identification (Reduced Size) (1) 553 Back Small Roof 1-1/4 x 28-15/16 x 21-7/8" - (1) 552 Front Small Roof 1 x 29 3/16 x 21-7/8" - Box 3 - 37599091 Box 3 - 37599098 (1) 512 Back Roof Panel 1-1/4 x 32 x 45"...
  • Page 16 ardware Identification (22) FW0 - 3 16 - 51103100 (3) LW2 - 5 16 - 51303300 (81) LW1 - 1 4 - 51303200 (47) TN1 - 1 4 54503200 (65) FW1 - 1 4 - 51103200 (132) LN1 - - 54303200 (23) TN2 - 5 16 54503300 (18) LN2 - 5 16...
  • Page 17 ard are dentification (Actual Size) Wafe Bolt 5/16 x 2-1/8" - (53613324) 1/4 x 1-3/8" 3 - Wafer Lag - (52613216) Wafer Bolt 5/16 x 2-3/8" - (53613326) 1/4 x 2-1/2" 5 - Wafer Lag - (52613222) Wafer Bolt 5/16 x 2-5/8" 10 - - (53613329) Hex Bolt 1/4 x 1-1/4"...
  • Page 18 Part Identification (Reduced Part Size) 1x - TNR4 Post Mount Clamp 1x - Cedar Summit (9203657) Plaque 1x - TNR4 Post Mount 1x - Kidkraft ID Paque (9320358) Base (9320370) 1x - Telescope w/ Mount (9203656) 31x - Square Nylok Nut...
  • Page 19 Europe Customer Service: +31 (0)20 305 8620 Online Parts Replacement: europecustomerservice@kidkraft.com Cedarsummitplay.com/parts-center-warranty-claim EU Online Parts Replacement: parts.kidkraft.eu Customer Service: 1(800) 933-0771 or (972) 385-0100 Read the assembly manual completely, paying special attention to EN71 and ASTM warnings; notes; and safety/maintenance information on pages 1 - 6.
  • Page 20 Step 2: Slide Wall Assembly A: Place (021) Narrow Back Panel against the left side of (022) Slide End Panel noticing panel orientation. The tops and bottoms of the panels should be flush and panels square. Pre-drill with a 3/16” drill bit, then fasten (021) Narrow Back Panel to (022) Slide End Panel with 4 (WL5) 1/4 x 2-1/2”...
  • Page 21 Step 3: Swing Wall Assembly A: Place (031) Panel Front Wall against the left side of (032) SW Wall Panel noticing panel orientation. The tops and bottoms of the panels should be flush and panels square. Pre-drill with a 3/16” drill bit, then fasten (031) Panel Front Wall to (032) SW Wall Panel with 4 (WL5) 1/4 x 2-1/2”...
  • Page 22 Step 4: Join Swing and Slide Wall Assemblies Part 1 A: With at least two helpers lift the Slide Wall Assembly and Swing Wall Assembly so the (021) Narrow Back Panel and (023) Narrow Front Panel meet with (033) Back Rock Panel and (031) Panel Front Wall and are tight together as shown in (fig.
  • Page 23 Step 4: Join Swing and Slide Wall Assemblies Part 2 C: From inside the assembly, tight to both (022) Slide End Panel and (032) SW Wall Panel, halfway up the assembly, 5/8” below the panel, loosely attach 1 (043) Side Joist to (021) Narrow Back Panel and (033) Back Rock Panel with 3 (WB10) 5/16 x 2-5/8”...
  • Page 24 Step 4: Join Swing and Slide Wall Assemblies Part 3 E: From inside the assembly, place 1 (044) Tie centred between (021) Narrow Back Panel and (033) Back Rock Panel so it is flush to the tops of the panels and the angled ends face out then attach with 2 (H10) 1/4 x 2-1/4” Hex Bolts (with lock washer, flat washer and t-nut) and 2 (S11) #8 x 2”...
  • Page 25 Step 4: Join Swing and Slide Wall Assemblies Part 4 G: On the inside of the assembly attach (021) Narrow Back Panel to (033) Back Rock Panel using 2 Flat Panel Brackets in the places shown with 4 (S8) #12 x 3/4” Pan Screws per bracket. (fig. 4.9 & 4.10) H: Repeat Step G to attach (023) Narrow Front Panel to (031) Panel Front Wall.
