Model 220
Batch Freezer
Operating Instructions
028763- M
5/99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taylor 220

Summary of Contents for Taylor 220

  • Page 1 Model 220 Batch Freezer Operating Instructions 028763- M 5/99...
  • Page 2 All rights reserved. 028763-M Taylor Company a division of Carrier Commercial Refrigeration, Inc. The word Taylor and the Crown design 750 N. Blackhawk Blvd. are registered trademarks in the United States Rockton, IL 61072 of America and certain other countries.

  • Page 3: Table Of Contents

    ............. . Table of Contents Model 220...
  • Page 4 E May, 1999 Taylor All rights reserved. 028763-M Taylor Company a division of Carrier Commercial Refrigeratio The word Taylor and the Crown design 750 N. Blackhawk Blvd. are registered trademarks in the United States Rockton, IL 61072 of America and certain other countries.

  • Page 5: To The Installer

    Taylor equipment. For Indoor Use Only: This unit is designed to operate indoors, under normal ambient temperatures of Only authorized Taylor service personnel 70_-75_F (21_-24_C). The freezer has successfully should perform installation and repairs on performed...

  • Page 6: Air Cooled Units

    National, State, and local codes symbol (5021 of IEC 60417-1) on both the removable for determining the proper configuration. panel and the equipments frame. 080911 To the Installer Model 220...

  • Page 7: Beater Rotation

    60245 IEC 57) installed with the proper cord anchorage to relieve conductors from strain, including twisting, at the terminals and Taylor reminds technicians to be cautious of protect the insulation of the conductors from government laws regarding refrigerant recovery, abrasion.

  • Page 8: To The Operator

    Taylor service technician. Taylor reserves the right to deny warranty claims on It should also be noted that Taylor does not warrant the equipment or parts if non--approved parts or refrigerant used in its equipment. For example, if the...

  • Page 9: Safety

    We at Taylor Company are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built--in safety DO NOT operate the freezer unless it is features to protect both you and the service technician.
  • Page 10 78 dB(A) when measured at a distance of 1.0 the beater asssembly. The scraper blades meter from the surface of the machine and at a height are very sharp. of 1.6 meters from the floor. 080911 Safety Model 220...

  • Page 11: Operator Parts Identification

    Section 4 Operator Parts Identification ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. PAN-DRIP 027503 SHELF-DRIP TRAY 031753 COVER A.-HOPPER-110-220 X24778 PANEL-FRONT LOWER 049441 GASKET-HOPPER COVER 011412 COLLAR-HOLDING 019481 PANEL-REAR 031749 FASTENER-CLIP 1/4-20 U-TYPE 045865 FUNNEL A.-MIX X35636 PANEL A.-SIDE LEFT* X49480 LOUVER-SIDE L &...

  • Page 12: Beater Door Assembly

    O-RING-2-1/8 OD X .139W-#225 020051 BEATER A. X32269 PISTON-VALVE 030083 BLADE-SCRAPER 052586 PIN-HINGE X04329 SHAFT-BEATER 032276 PIN A.-PIVOT X34737 SEAL-DRIVE SHAFT 031316 DOOR A.-PARTIAL SPOUT X32938 SCREW A.-CROSS BAR X07233 CAP A.-COVER X29667 BAR-CROSS 011740 Operator Parts Identification Model 220...

  • Page 13: Accessories

    PART NO. ITEM DESCRIPTION PART NO. PAIL-MIX 10 QUARTS 013163 LUBRICANT-TAYLOR 047518 BRUSH-MIX TANK BODY 3”X7” 023316 SANITIZER KAY-5 125 PKTS. 041082 BRUSH-DRAW VALVE 1-1/2”X3” 014753 FUNNEL-PLASTIC DOOR 029670 BRUSH-REAR BRG 1”X2”X14” 013071 PLUNGER A. X09585 Model 220 Operator Parts Identification...

  • Page 14: Important: To The Operator

    When the control switch is in the “AUTO” words on many of our operator switches and buttons position, this light will come on, indicating the have symbols to indicate their functions. Your Taylor refrigeration system is operating. equipment is designed with these International symbols.

  • Page 15: Operating Procedures

    Section 6 Operating Procedures The Model 220 freezer can produce all flavors of ice cream, including those with fruits and nuts. The freezer is designed for filling pints, quarts or gallons to be placed in a hardening cabinet. The unit has a 10 quart (9.5 liter) mix hopper.
  • Page 16 When in position, the beater will not protrude beyond the front of the freezing cylinder. Figure 8 Operating Procedures Model 220...
  • Page 17 Figure 10 Figure 13 Thread the valve piston on the end of the draw rod until Turn the draw rod handle to lock the bearing holder into tight. place. Figure 11 Figure 14 Model 220 Operating Procedures...
  • Page 18 Make sure the freezer door fits securely over the freezing cylinder. With the door seated over the front of the freezing cylinder, install the cross bar screw assembly in the center of the freezer door through the cross bar. Tighten securely. Figure 19 Operating Procedures Model 220...

  • Page 19: Sanitizing

    [7.6 liters] of Stera--SheenR). USE WARM WATER FOLLOW MANUFACTURER’S SPECIFICATIONS. Figure 23 Step 4 While the solution is flowing into the freezing cylinder, brush clean the hopper and the mix inlet hole. Figure 21 Figure 24 080911 Model 220 Operating Procedures...
  • Page 20 Allow to agitate for five Figure 27 minutes. Step 7 Assemble the hopper gasket around the top edge of the mix hopper. Figure 26 Figure 28 Operating Procedures Model 220...

  • Page 21: Priming

    Step 2 mix pail. Pour 10 quarts (9.5 liters) of FRESH mix into the hopper. This should bring the mix level up to the second graduated mark on the rear wall of the hopper. Figure 31 060425 Model 220 Operating Procedures...
  • Page 22 This light is a visual signal that the product is down to the hopper in readiness for the next batch while the first its proper temperature. Place the control switch in the batch of mix is freezing. “OFF” position. Figure 33 Figure 35 Operating Procedures Model 220...

  • Page 23: Overrun

    “EJECT” position to agitate the product and blend more air into the mixture. Continue to take samples until the desired overrun is obtained. Step 1 Use a standard overrun scale and a one pint (1/2 liter) measuring cup. Figure 39 060425 Model 220 Operating Procedures...
  • Page 24 When the container is full, push the draw the mix hopper. With the brushes provided, scrub the rod back into the valve body and lock into place. mix hopper and the mix inlet hole. Operating Procedures Model 220...
  • Page 25 Remove the keeper pin from the draw rod back into the valve body and lock into the cover cap assembly and remove the cover cap place. assembly. 080911 Model 220 Operating Procedures...
  • Page 26 Place all the cleaned parts on a clean dry surface to air dry overnight. Figure 41 Step 6 Wipe clean the shelf and all exterior surfaces of the freezer. Operating Procedures Model 220...
  • Page 27 7. The temperature of finished product to be maintenance purposes. Deteriorated placed in a hardening cabinet should be cracked water lines should be replaced only by between 23_ and 25_F (--5.0_ to -- 3.9_C). an authorized Taylor technician. 051101 Model 220 Important: Operator Checklist...
  • Page 28 Winter Storage If the place of business is to be closed during the winter Your local Taylor Distributor can perform this service months, it is important to protect the freezer by for you. following certain precautions, particularly if the Wrap detachable parts of the freezer such as the building is subject to freezing conditions.
  • Page 29 Rear shell bearing is worn. c. Contact a service -- -- technician. d. The wrong type of d. Use Taylor Lube. -- -- lubricant is being used. 6. Buzzer does not sound a. Buzzer is malfunctioning. a. Contact a service -- -- technician.
  • Page 30 “OFF” some product out to place position. Return to freezer in hardening cabinet. to draw out more product, place control switch in the “EJECT” position. Troubleshooting Guide Model 220...
  • Page 31 Black Bristle Brush, 1” x 2” Inspect & Minimum Replace if Necessary White Bristle Brush, 1--1/2” x 2” Inspect & Minimum Replace if Necessary White Bristle Brush, 3” x 7” Inspect & Minimum Replace if Necessary Model 220 Parts Replacement Schedule...
  • Page 32 Section 10 Parts List + Available Separately Parts List Model 220...
  • Page 33 + Available Separately Model 220 Parts List...
  • Page 34 + Available Separately Parts List Model 220...
  • Page 35 + Available Separately Model 220 Parts List...
  • Page 36 + Available Separately Parts List Model 220...
  • Page 37 Model 220 030385 3/10...
  • Page 38 Model 220 030385 Inset 3/10...
  • Page 39 Model 220 030385- -33 3/10...
  • Page 40 Model 220 030385- -62 3/10...
