directly above a heat source, (e.g. fire, radiator, boiler, etc). Where possible, mount the detector in the
corner of the room so that the logical path of an intruder would cut across the fan detection pattern.
PIR detectors respond more effectively to movement across the device than to movement directly
towards it. Where possible, mount the detector in the corner of the room so that the logical path of an
intruder would cut across the fan detection pattern.
Carefully drill out the required mounting holes in the rear cover; A. Using the rear cover as a template,
mark the positions of the fixing holes on the wall. Fix the rear cover to the wall. Detection area is
adjustable up to 12 meter; you can move the PCB up or down. Check again if Dip 4 of SW3(dipswitch
1-5) in Off. In test mode the PIR will send after every trigger a signal. In the regular mode the PIR will
pause 2 minutes, and then send again a signal after being triggered, to save batteries.
Programming the Alarm Panel:
We advise to do the programming before mounting the Alarm Panel. First we change from the Walk Test
mode to the Program/Install mode. Press
time! Now we go into the Program/Install mode; mentioned further Inst. mode:
Press , 1 2 3 4
First we will change the Master Password! Press
display: 1-7 MASTER SETUP, Press
Enter Password Code: NOW PRESS YOUR NEW CODE! and
Check if ???? is the password you entered. If ok, press 2x
display: 1-1 USER 1 SETUP, Press
Password Code: NOW PRESS THE CODE FOR USER 1 and
Password you entered, CHECK! After the password
Next step is that we define some standard settings, per sensor ; press
display:
1. USER SETUP. Press
Zone Setup (Z1-10) ; fill in the Zone Number you defined in the sensors!
Name
Type
Final Exit
Chime
Entry Delay Zone 1
Zone 2-10
Part-Arm 1
Part-Arm 2
Walk Through
Select all the zones you defined in the sensors!
Less Sensitive More Sensitive
(1 2 3 4 standard Master Password), display show 1.USER SETUP.
, display: :1 Password. Press
,until in display: 3. ZONE SETTING. No we can choose:
No Name
Intruder
OFF
OFF
ON, 30s
OFF
OFF
OFF
OFF
A
until you see in the display: 'DISARM READY" and the
: 1-1 USER 1 SETUP. Press
, display: :1 Password 1234 , Press
,display: 1. USER SETUP, Press
You can select a room name, or leave 'no name'
Normal sensor will be 'intruder'.
'OFF'
'OFF'
Depends if you have to pass the
when you leave, or come back!
Do you want switch this sensor on in PARM1
Do you want switch this sensor on in PARM2
'OFF'
A 1=6, 2=9,3=12m
, display:
, display: :1 Password ???? .
, display: Enter
, display : will show the
until you see in the
