- Page 1 Operation & Installation Manual Wireless Controller - CIR01 - IMPORTANT: READ AND UNDERSTAND THIS MANUAL BEFORE USING THIS WIRELESS CONTROLLER. KEEP THIS MANUAL FOR FUTURE REFERENCE. P5415475 LIT-12012036...
- Page 2 Important Notice ● Johnson Controls Inc. pursues a policy of continuing improvement in design and performance in its products. As such, Johnson Controls Inc. reserves the right to make changes at any time without prior notice. ● Johnson Controls Inc. cannot anticipate every possible circumstance that might involve a potential hazard.
-
Page 3: Safety Messages
Use only Johnson Controls recommended, provided as standardized, or replacement parts. ● Johnson Controls shall will not assume any liability for injuries or damage caused by not following steps outlined or described in this manual. Unauthorized modifications to Johnson Controls products are prohibited as they…... -
Page 4: Installation Precautions
● If the wired controller is installed in a location where electromagnetic radiation is generated, make sure that the wired controller is shielded and cables are sleeved inside conduit tubing. ● If there is a source of electrical interference near the power source, install noise suppression equipment (filter). - Page 5 ● Use an exclusive power supply at the controller’s rated voltage. ● Be sure to install circuit breakers (ground fault interrupter, isolating switch, molded case circuit breaker, and so forth) with the specified capacity. Ensure that the wiring terminals are tightened securely to recommended torque specifications.
-
Page 6: Setting Batteries
● Do not turn ON the power source, unless the preparations for the test run are completed. ● Read this manual together with the installation and maintenance manual of the indoor unit. Brand Label NOTE: Either the York or the Hitachi logo label, but not both, will be shipped with the unit. -
Page 7: Name Of Parts
3. Name of Parts Controller: ● This controller is used to send commands about the operation mode and timer settings for the indoor unit. Point the transmitter of the controller toward the receiver of the indoor unit and press the button for the required operation so that commands (by infrared beam) are sent to the indoor unit. -
Page 8: Installation Method
When the receiver kit receives the commands, the indication light (yellow) TIMER FILTER DEF on the receiver kit turns ON for an EMERGENCY CIR01 instant, and the buzzer sounds. HEAT COOL Receiver ATTENTION: * The capable distance for transmitting using the wireless remote controller is maximum 20 feet (6 meters). - Page 9 6. Optional Function Setting The display range of the wireless controller can be set, following the function to set the indoor unit. ATTENTION: The settings cannot operate correctly even if the functions which cannot set the indoor unit, are set with the wireless controller. Concerning the functions which can set the indoor unit, refer to the operation manual of the indoor unit.
- Page 10 7. Identifying Indoor Units Installed Side by Side Operation ● Purpose This function is used when operating several receivers or indoor units side by side, to prevent a malfunction because of receiving incorrect signals from the wireless remote controllers used in other areas. Only the communication between the paired setting is possible, and four pairs (A, B, C, D) are available.
- Page 11 8. Test Run with the Controller 1. Turn ON the power supply for the indoor units. The “ ” light (yellow) on the receiver kit of the indoor unit flashes (0.25 seconds ON 0.25 seconds OFF), and then turns OFF. While the light is flashing, the unit will not operate because it is initializing. 2.
- Page 12 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. © 2015 Johnson Controls, Inc. LIT-12012036 P5415475...
