00

Tightening torque

Model
Connection

11 Engine

Cylinder head
Tightening sequence:
1 Tighten cylinder head nuts (oiled) in go-
nally opposite sequence
1.1 Tighten all nuts to closing torque
1.2 Tighten all nuts to correct angle
1.3 Tighten all nuts to correct angle
2 M 10 screw
3 M 6 screw
After 1,000 km (600 miles), tighten cylinder
head nuts in diagonally opposite se-
quence:
1 Slacken one nut
2 Tighten nut to initial torque
3 Tighten nut to wrench angle
4 Slacken and retighten M 10 screw
Timing gear carrier to cylinder head
Bearing cap on rocker shaft
Locknut, valve adjusting screw
Cylinder head cover to cylinder head
Camshaft end cover to cylinder head
Air intake connection to cylinder head
Camshaft
Chain sprocket to camshaft
Camshaft bearing cap
Alternator mount cover
M 6 screw
M 8 screw
Auxiliary shaft
Chain sprocket to crankshaft
Chainwheel to auxiliary shaft
Chain tensioner housing to engine block
R 1150 R
Nm 20
° 90
° 90
Nm 40
Nm 9
Nm 20
° 180
Nm 40
Nm 9
Nm 18
Nm 8
Nm 8
Nm 9
Nm 9
Nm 65
Nm 15
Nm 9
Nm 20
Nm 10
Nm 70
Nm 9
00.3
