ICP-CC404 | Quick Reference Guide |
Figure 8: WE800/E Wireless On/Off Interface
1 – Direct link cable
2 – Receiver interface connection
3 – Wireless On/Off Interface
4 – Red
18
5 – Black
6 – Termination for phone line
7 – Socket for telecom lead connection
Bosch Security Systems, Inc. | 10/08 | F01U089402-01
