- Page 1 BOTTLE JACK MODEL NO: CBJ2,3,5,8,10,12,15 & 20B PART NO: 7620006,7620008,76200012,7620022,7620027,7620032,7620034 & 7620037 OPERATION AND MAINTENANCE INSTRUCTIONS GC0615...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Bottle Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 1. Do not exceed the rated capacity of the jack. 2. Do not allow personnel to operate the jack unless they have read these safety precautions. 3. Do not operate the jack if damaged. 4. Use the jack in a suitable, well lit work area. 5. -
Page 4: Safety Symbols
20. Never push a vehicle off the jack or start the engine while supported only by the jack. 21. Do not use if an oil leak is apparent. Consult the Clarke Service Department. 22. If more than one jack is used in unison, they must all be of the same rating and be raised at the same speed/height to reduce the possibility of the load slipping. -
Page 5: Product Features
PRODUCT FEATURES (CBJ5B shown) Handle Tubes Screw Extension Oil Filler Plug Actuating Lever Release Valve Safety Valve (non-adjustable) UNPACKING During transit or storage, it is possible that an air pocket may have developed within the hydraulic ram, and the ram action may therefore appear to be ‘spongy’. -
Page 6: Operation
OPERATION WARNING: ENSURE THE SAFETY PRECAUTIONS ARE STRICTLY FOLLOWED. NO RESPONSIBILITY CAN BE ACCEPTED FOR INCORRECT USE OF THE JACK. RAISING A VEHICLE 1. Ensure the vehicle is stable and is on firm level ground with the wheels chocked before positioning the jack so that is directly beneath the lifting point. -
Page 7: Maintenance
Do not use the jack unless it is perfectly serviceable. • A slight dampness on the ram is normal, but where leakage is found, the ram seals must be renewed by your Clarke Service Department. 2. The jack should be fully inspected annually as follows: •... -
Page 8: Purging Air From The Jack
4. Do not overfill. Only use the correct type of oil such as Clarke hydraulic oil (part number 3050830). 5. Replace the filler plug. 6. Check the jack for correct operation and purge any air from the system as described below. -
Page 9: Component Parts
Hinge Pin Piston Pump Plunger Oil reservoir Pump Body Filler Plug O-ring Extension Screw Please contact the Clarke Spares Department for availability of seal kits, handles or other component parts. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Also Available From Clarke
ALSO AVAILABLE FROM CLARKE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
