Restore the "out of box" factory condition.
1. At the back of the lock, remove the screw at the bottom of the lock housing and remove the cover.
2. Disconnect the battery pack connector.
3. With battery power disconnected, short the two white wires (Remote Input wires) together for 10 seconds to
ensure discharge of all capacitors. After 10 seconds, remove the short.
4. Re-connect the battery pack. The lock will immediately sound 3 short beeps (if these 3 beeps are not heard,
then restart at step 3). Within 3 seconds, hold down the outside handle.
5. The lock will then sound more slow beeps, 1 beep for every second it takes to clear the memory. Release the
handle.
6. Lock is ready for programming after 2 rapid beeps are heard and 2 green LED flashes are seen.

Power Up--Retain Existing Programming

Use when re-applying power to a lock already in use (you wish to retain the Lock Program), such as when moving
an existing lock to a new door. The lock must be dismantled and powered down for an extended period.
1. Disconnect battery pack connector.
2. With battery power disconnected, short the two white wires (Remote Input wires) together for 10 seconds to
ensure discharge of all capacitors.
3. Without touching or turning the handle, re-connect the battery pack (lock will sound 3 short beeps). If
these 3 beeps are not heard, then restart at step 1. The lock will perform several self tests; when complete, 7
beeps and LED flashes will sound. The lock is now ready for use.
Verifying Proximity Card and Keyfob Access
Test by simply presenting a valid proximity card or fob to the reader in front of the lock.
VALID CARD - Green LED flashes, the sounder beeps several times and the PL6600/ETPLNRX unlocks.
INVALID CARD - Red LED flashes several times and the sounder beeps several times.
With a fully charged battery, the LED and sounder provide visual and audible feedback as follows:
ACTIVITY
Access Granted or
Remote Release
Invalid Card / Fob
Valid but Disabled
1 green, 4 red flashes
Card / Fob
Emergency Commands 1 red flash every two
are in effect
1 red flash once every
Door Ajar second (continues for xx
Forced Door Detection
(door "kick-in")
Low Battery

Erase All Programming

Testing the Cards Entered

LED and Sounder Indicators

LED SOUNDER
2 green flashes
7 red flashes
1 Long, 5 Short Beeps
seconds
seconds)
Steady tone
--
for xx seconds
Red LED and Sounder turn on steady for the
duration of the "Pass Time".
2 Beeps
An invalid proximity card / fob does not exist in the Lock
7 Beeps
Program memory.
A proximity card / fob exists in the firmware, but is disabled.
--
--
See page 8 ("Battery Replacement) before changing
batteries. ("Pass Time" is the duration the lock remains
COMMENTS
--
--
--
unlocked after access is granted).
9
