C

Data

C.1

Drive

Power and current ratings
The input current is affected by the supply voltage
and impedance. Therefore, to aid the selection of
cables and fuses, the values of Maximum
continuous input current stated are for the
worst-case condition.
The values of maximum current for models 1201 to
1205 are stated for a 200V
times the kVA of the Drive, with 2% negative
phase-sequence imbalance and a typical motor load.
The values of maximum current for models 2201 to
2203 and 3301 to 3304 are stated for a 200V
supply having a 5kA short-circuit capability and a
AC
2% negative phase-sequence imbalance.
The values of Typical input current are stated
for a balanced 200V
AC
short-circuit capability; these values are given to aid
calculations for power flow and power loss.
Unidrive LV and Unidrive VTC LV
(at 40° ° C ambient temperature)
Model
kW
UNI 1201 0.37 kW
UNI 1202 0.55 kW
UNI 1203 0.75 kW
UNI 1204 1.1 kW
UNI 1205 2.2 kW
UNI 2201 3.0 kW
UNI 2202 4.0 kW
UNI 2203 5.5 kW
UNI 3201 7.5 kW
UNI 3202 11 kW
UNI 3203 15 kW
UNI 3204 22 kW
Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
supply rated at ten
AC
supply having a 5kA
Nominal
rating
HP 3kHz
0.5 2.1 A
0.75 2.8 A
1.0 3.8 A
1.5 5.6 A
3.0 9.5 A
4.0 12.0 A
5.0 16.0 A
10.0 25.0 A
15.0 34.0 A
20.0 46.0 A
25.0 60.0 A
30.0 74.0 A
Maximum permissible
continuous output current
4.5kHz 6kHz 9kHz
2.1 A 2.1 A
2.8 A 2.8 A
3.8 A 3.8 A
5.6 A 5.6 A
9.5 A 8.5 A
12.0 A 12.0 A 12.0 A
16.0 A 16.0 A 14.2 A
21.7 A 18.2 A 14.2 A
34.0 A 34.0 A 28.0 A
46.0 A 40.0 A 32.0 A
47.0 A 40.0 A 32.0 A
56.0 A 46.0 A 35.0 A
Typical
input
current
12kHz
2.1 A 2.1 A 2.4 A
2.8 A 2.8 A 3.5 A
3.8 A 3.8 A 4.6 A
5.6 A 4.5 A 6.5 A
7.0 A 5.5 A 8.6 A
11.7 A 10.8 A
11.7 A 14.3 A
11.7 A 19.8 A
23.0 A 26.0 A
26.6 A 39.0 A
26.7 A 53.0 A
28.0 A 78.0 A
Data
Maximum
cont.
input
current
4.0 A
6.0 A
8.0 A
10.0 A
12.5 A
13.9 A
16.9 A
27.0 A
28.0 A
43.0 A
56.0 A
84.0 A
C-1
