4

Data

4.1

Specifications

Maximum input voltage to Drive (L1, L2 and L3, i.e. main power to
thyristor bridge)
480V +10% standard
525V +10% optional
660V +10% special order
Maximum recommended motor voltage
Varm = 1.15 x Vsupply
Input power supply voltage (E1, E2 and E3, i.e. auxiliary power
supply)
Balanced 3-phase 3-wire, 45Hz to 62Hz, maximum 480V +10%.
With the higher voltage (525V, 660V) versions the maximum power
supply voltage is also 480V +10%.
The input to the control (electronic) circuits is:
Standard -2-wire, 220V - 10% to 480V +10%
With North American field bridge -3-wire, 220V - 10% to 480V +10%
NOTE
E1 & E3 must be connected to the same phases as L1 & L3
Output supplies and references (Short-circuit proof)
10V reference ±5% 10mA Drive capability.
Encoder supply 300mA Drive capability at 5V, 12V or 15V selectable.
+24V supply 200mA Drive capability for relays.
All outputs are wire-proof - unaffected by accidental short circuiting.
Ambient temperature & humidity
Rated ambient temperature 40°C (104°F)
Rated maximum altitude 1000m (3200ft).
Storage temperature range -40°C to +55°C (-40°F to 131°F)
Humidity requirement non-condensing.
Derating
Nominal ratings are affected by:
1. The altitude of the installation.
Where the site is above 1000m (3200ft), reduce the normal full load
current by 1.0% for each additional 100m (320ft), up to a maximum
of 4000m.
2. The ambient temperature.
Where the local ambient temperature is above 40°C (104°F), derate
by 1.5% per °C up to 55°C (0.75% per °F up to 131°F).
Enclosure Ingress Protection
Mentor II Drives are constructed in accordance with European IP00
specification. Mentor II Drives are suitable for mounting in NEMA
ingress-protected enclosures.
The Drive must be protected against moisture and conductive
contamination. The Drive is intended for use in pollution degree 2
environments.
Mentor ll User Guide
Issue Number: 12
4.2

Ratings

4.2.1 Current, input and output
Mentor is suitable in a circuit capable of delivering no
more than 10000 RMS symmetrical amperes for M25-
M210 and M25R-M210R and 18000 RMS symmetrical
amperes for M350-M825 and M350R-M825R short
CAUTION
circuit current, 480V +10% maximum.
Drive type & model
Single
Quadrant Quadrant
M25
M45
M75
M105
M155
M210
M350
M420
M550
M700
M825
M900
M1200 M1200R
M1850 M1850R
• Motor rating may be increased at higher armature voltages
Refer to Maximum recommended motor voltage in section
4.1 Specifications .
www.controltechniques.com
Typical* ratings
at 400V at 500V
Four
(armature) (armature)
kW HP kW
M25R 7.5 10 9
M45R 15 20 19
M75R 30 40 38
M105R 37.5 50 47
M155R 56 75 70
M210R 75 100 94
M350R 125 168 156
M420R 150 201 188
M550R 200 268 250
M700R 250 335 313
M825R 300 402 375
M900R 340 456 425
450 603 563
750 1005 938
Maximum
continuous
current rating
input output
HP Aac Adc
12 21 25
25 38 45
50 60 75
63 88 105
94 130 155
126 175 210
209 292 350
252 350 420
335 460 550
420 585 700
503 690 825
570 750 900
755 1000 1200
1258 1540 1850
