Control Techniques Unidrive LV Series Installation Manual page 31

Mounting the RFI filter
The RFI filters can be surface-mounted only.
Mount the RFI filter at the specified location in
relation to the Drive. In the case of filter sizes C to
D, ensure the terminals face the Drive.
LOAD
Figure 2–17 Principal dimensions of RFI filters
sizes A and B, and the locations of
the terminals
Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
Dimension RFI filter size
A
4200–0010
C 378mm
7
14 / in
8
D 114.5mm
1
4 / in
2
E 335mm
3
13 / in
16
F 25mm
1 in
G 6.4mm
1
/ in
4
H 396mm
9
15 / in
16
J 10mm
3
/ in
8
W 50mm
15
1 / in
16
Installing the Drive
B
4200–0027
388mm
1
15 / in
4
114.5mm
1
4 / in
2
335mm
3
13 / in
16
37.5mm
1
1 / in
2
6.4mm
1
/ in
4
406mm
16 in
10mm
3
/ in
8
75mm
15
2 / in
16
2-25
