Control Techniques Unidrive LV Series Installation Manual page 53

The optional RFI filter specified below must be used:
Drive model
Type
UNI 1201
UNI 1202
UNI 1203
UNI 1204
UNI 1205
UNI 2201
UNI 2202
UNI 2203
UNI 3201
UNI 3202
UNI 3203
UNI 3204
Model size
UNI 1201 ~ UNI 1205 Restricted distribution only: specified RFI filter required
(Rated input current
of Drive <25A)
UNI 2201, UNI 2202 Restricted distribution only: specified RFI filter required
(Rated input current
of Drive <25A)
UNI 2203 Specified RFI filter required
(Rated input current
of Drive >25A)
UNI 3201 ~ UNI 3204 Specified RFI filter required
(Rated input current
of Drive >25A)
RFI filter(s) recommended where sensitive electronic systems are operating nearby.
Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
Use RFI filter...
Part number
A 4200–0010
A 4200–0010
A 4200–0010
A 4200–0010
A 4200–0010
B
4200–0027
B 4200–0027
B 4200–0027
C 4200–1051
C 4200–1051
D 4200–1071
D 4200–1071
Power Drive Systems standard EN61800–3
First environment
Power Drive Systems standard
EN61800–3
The Drive meets the immunity requirements of
EN61800–3 irrespective of the environment in which
it is operating.
The emission requirements of this standard are also
met depending on the environment category, as
shown in the table below.
EN61800–3 defines the following:
•
The first environment as one that
includes domestic premises. It also includes
establishments directly connected without
intermediate transformers to a low-voltage
power supply network which supplies
buildings used for domestic purposes.
•
The second environment is one that
includes all establishments other than those
directly connected to a low-voltage power
supply network which supplies buildings
used for domestic purposes.
•
Restricted distribution is defined as a
mode of sales distribution in which the
manufacturer restricts the supply of
equipment to suppliers, customers or users
who separately or jointly have technical
competence in the EMC requirements of the
application of Drives.
Note
If a Power Drive System is included as part
of equipment covered by a separate EMC
product standard, the EMC standard for the
complete equipment applies.
Environment category
Second environment
No RFI filter required *
No RFI filter required *
No RFI filter required *
No RFI filter required *
Data C-5
