1243 2 SYSTEM FAULTS MENU
GEN
This is a list of the possible fault messages you may see displayed by the
programmer. The messages are listed here in alphabetical order for easy refer-
ence.
ANTI-TIEDOWN
FIELD SHORT
CURRENT SHUNT FAULT
EMR REV WIRING
FIELD OPEN
HPD
HW FAILSAFE
LOW BATTERY VOLTAGE
M- SHORTED
MAIN CONT WELDED
MISSING CONTACTOR
MOTOR HOT
MOTOR WARM
NO KNOWN FAULTS
OVERVOLTAGE
SRO
SRVC TOTAL
SRVC TRAC
THERMAL CUTBACK
THROTTLE WIPER HI
THROTTLE WIPER LO
TOTAL DISABLED
TRAC DISABLED
Note: If you are using the older 1307 programmer,
the 1311's System Faults Menu is called the Diagnostics Menu.
6 — PROGRAMMER MENUS:
Mode Select 1 switch closed at startup
Contactor coil or motor field winding shorted
Current sensor error
Emergency reverse wiring check failed
Motor field winding open
High pedal disable (HPD) activated
Hardware failsafe activated
Battery voltage too low
M- shorted to B-
Welded main contactor
Missing contactor
Field winding resistance at disable setpoint
Field winding resistance at cutback setpoint
No known faults
Battery voltage too high
Static return to off (SRO) activated
Total service timer expired
Traction service timer expired
Cutback, due to over-/undertemperature
Throttle wiper input too high
Throttle wiper input too low
Total disable timer expired
Traction disable timer expired
Diagnostics/Faults Menu
