Program Menu,
cont'd
M2 MAX REV SPD Mode 2 maximum reverse speed, as % drive output
Mode 3 maximum reverse speed, as % drive output
M3 MAX REV SPD
Mode 4 maximum reverse speed, as % drive output
M4 MAX REV SPD
CREEP SPEED Creep speed, as % drive output
Type of throttle input
THROTTLE TYPE
THRTL DEADBAND Throttle neutral deadband, as %
Throttle input req'd for 100% drive output, as %
THROTTLE MAX
Drive output at 50% throttle input, as %
THROTTLE MAP
Minimum field current, in amps
FIELD MIN
Maximum field current, in amps
FIELD MAX
FLD MAP START Armature current at which field map takes effect, in amps
Field current map setting, as %
FIELD MAP
CURRENT RATIO Current ratio: factor of 1, 2, 4, or 8
Mode 1 restraint braking, in amps
M1 RESTRAINT
M2 RESTRAINT Mode 2 restraint braking, in amps
Mode 3 restraint braking, in amps
M3 RESTRAINT
Mode 4 restraint braking, in amps
M4 RESTRAINT
LOAD COMP Load compensation: 0 to 25% drive output
High pedal disable (HPD) type
HPD
SRO Static return to off (SRO) type
Sequencing delay, in seconds
SEQUENCING DLY
Main contactor uses interlock input: On or Off
MAIN CONT INTR
MAIN OPEN DLY Main contactor open delay: On or Off
Contactor diagnostics: On or Off
CONT DIAG
AUX TYPE Auxiliary driver type
Auxiliary driver open delay, in seconds
AUX DELAY
EMR REV C/L Emergency reverse current limit, in amps
Emergency reverse wiring check: On or Off
EMR REV CHECK
Emergency reverse direction interlock: On or Off
EMR DIR INTR
Variable braking: On or Off
VARIABLE BRAKE
Anti-tiedown: On or Off
ANTI-TIEDOWN
POT LOW FAULT Pot Low fault: On or Off
Voltage considered 100% state of charge, in volts
FULL VOLTS
Voltage considered 0% state of charge, in volts
EMPTY VOLTS
RESET VOLTS Voltage at which state of charge resets to 100%, in volts
BATTERY ADJUST
BDI algorithm adjustment to compensate for battery capacity, in secs
BDI LOCKOUT Fault 2 output high when BDI%=0: On or Off
Battery s-o-c <1% invokes BDI Limit Speed: On or Off
BDI DISABLE
