Program Menu,
cont'd
ADJ HRS LOW Hourmeter preset low byte: 0–99
Hourmeter preset middle byte: 0–99
ADJ HRS MID
Hourmeter preset high byte: 0–99
ADJ HRS HIGH
SET TOTL HRS Apply preset values to total hourmeter: On or Off
Apply preset values to traction hourmeter: On or Off
SET TRAC HRS
HOURMETER TYPE Total hourmeter is default display: On or Off
Total service timer setting, in hundreds of hours
SRVC TOTL HRS
SRVC TRAC HRS Traction service timer setting, in hundreds of hours
Reset total service timer: On or Off
SRVC TOTL
Reset traction service timer: On or Off
SRVC TRAC
Total disable timer setting, in hours
DIS TOTL HRS
Total traction timer setting, in hours
DIS TRAC HRS
TRAC FAULT SPD Max. drive speed if disable timer expires, as %
Max. drive speed upon BDI disable, as %
BDI LIMIT SPD
WARM SPEED
Max. drive speed if Mot Wrm resistance exceeds setpoint, as %
MOT WRM 10
Ω Field resistance setpoint for Warm Speed, in 10-milliohm units
x m
MOT HOT 10 Field resistance at which no drive output, in 10-milliohm units
Ω
x m
MOTOR Ω COMP
Enable cutback/cutoff response to motor overtemp.: On or Off
Max. intk braking regen current fr. rev., max. load, in amps
MAX REV REGEN
MAX FWD REGEN Max. intk braking regen current fr. fwd., max. load, in amps
Max. intk braking regen current fr. rev., min. load, in amps
MIN REV REGEN
MIN FWD REGEN Max. intk braking regen current fr. fwd., min. load, in amps
MAX LOAD VOLTS Voltage on load sensor for max. regen current, in volts
MIN LOAD VOLTS Voltage on load sensor for min. regen current, in volts
INT BRAKE DLY Delay before E-M brake applied after intk switch opens, in secs
Fault code: On or Off
FAULT CODE
EM BRAKE PWM Enables modulation of brake driver output: On or Off
Fault will register if open detected in field: On or Off
FIELD CHECK
PUMP METER
Enables use of Pin 2 as input for a pump hourmeter: On or Off
