- Page 1 User manual AH17D1HDA2F AH19D1HDA2F AH22D116A2F › › Retractable›double›screen›monitors›for›integration›in›furniture.
- Page 2 User manual About us The›company Arthur› Holm› has› its› origins› in› the› Danish› furniture› designer› Jorgen› Alex› Jensen,› who› was› active› during› the› sixties› and› the› seventies.›His›design›inspiration›and›his›concept›of›ergonomics›have›been›continued›by›his›family,›the›design›force›behind› Arthur›Holm›product›range.›The›result›of›combining›Scandinavian›design›tradition›with›Mediterranean›creativity,›flexibility›and› emotion›is›a›wide›product›range›built›on›more›than›20›years›of›craftsmanship. Arthur› Holm› offers› a› professional› product› range› where› tomorrow’s› technology› is› shaped› into› valued› materials› with› design› flexibility›...
- Page 3 User manual Welcome Thank›you›for›purchasing›an›ARTHUR›HOLM›product. Our›product›range›has›been›designed›to›create›the›perfect›meeting›room,›where›the›screens›are›a›part›of›the›interior›design› as›well›as›essential›communication›tools. Please›read›these›installation›and›operation›instructions›carefully›and›keep›them›in›a›safe›place›for›future›reference. We›remain›at›your›disposal›if›you›have›any›suggestions›that›would›help›us›improve›our›products. Henrik›Holm General›Manager...
-
Page 4: Table Of Contents
User manual Table of contents EC›Normative›and›Security›Norms Applications›and›Features Box›Contents› Controls OSD›Menu Input›Connections AHnet›Protocol Input›Resolutions Disposal›Information Warranty... -
Page 5: Ec Normative And Security Norms
User manual EC Normative and Security Norms ATTENTION: Do not disassemble or modify the device in any way This›symbol›warns›of›the›presence›of›dangerous›non-insulated›voltages›inside›some› of›the›components,›which›are›high›enough›to›cause›risk›of›electric›shock. This›symbol›draws›attention›to›important›use›and›maintenance›instructions›in›the› manual›that›accompanies›the›unit. This›symbol›indicates›that›the›equipment›conforms›to›the›norms›established›by›the› European›Community. Safety instructions PLUGS Do›not›dismantle›any›part›of›the›monitor›power›connector. Disconnect›the›power›plug›from›the›AC›outlet›when›the›monitor›is›not›going›to›be›used›for›a›long›period. POWER AND EXTENSION CORDS Use›the›appropriate›power›cord›with›the›correct›plug›type. Do›not›overload›wall›outlets›or›power›cords. Make›sure›the›total›ampere›passed›through›an›extension›cord›does›not›exceed›the›maximum›allowed›by›the›cable›used. Do›not›place›anything›on›the›power›cord. Do›not›locate›this›product›where›a›person›may›trip›or›walk›over›the›cord. - Page 6 User manual EC Normative and Security Norms Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables For your safety, your equipment must be connected to an electrical outlet with grounding connection protection The›operating›electrical›outlet›must›be›in›an›easily›accessible›place.
-
Page 7: Applications›And›Features
When› being› in› the› starting› position› (retracted)› the› screen› is› placed› inside› the› table› leaving› the› desk› free› of› any› obtrusive› element.›When›in›this›position,›electricity›will›be›automatically›disconnected›to›save›energy›and›preserve›the›panel›life. By›pressing›the›open/close›button›located›on›the›top›of›the›screen,›the›TFT›panel›rises›up›into›the›working›position.›The›TFT› power›is›then›restored. Features › › Two›TFT›Active›Matrix›display›22’’›Full›HD › – AH17D1HDA2F› 17’’›Full›HD › – AH19D1HDA2F› 19’’›Full›HD › – AH22D116A2F› 22’’›Full›HD › › Retractable›monitor›with›electrical›engine› › for›integration›in›furniture› › › Up/Down›function›operated›by›two›buttons›on›the›cover›plate ›... -
Page 8: Box Contents
User manual Box Contents Box Contents Before›the›installation›of›this›retractable›monitor,›please›check›the›contents›of›the›shipping›box.›It›must›contain›the›following› items: › › Monitor › › Power›cord › › User›manual › › Power›supply›100-240Vac,›50-60Hz.›Output›12V › › Remote›control›(1›per›5›monitors) CAUTION: Never use this monitor in horizontal position Before connecting (power): 1.› Open›the›hatch›and›remove›the›two›foam›protection›pieces.› 2.› Install›the›unit›on›a›table›or›desk›in›vertical›position. Power connection: 1.›... -
Page 9: Controls
User manual Controls Controls Remote›control: POWER:›Turns›ON/OFF›the›monitor MENU:›Activates›the›OSD›menu UP:›Moves›cursor›up RIGHT:›Moves›cursor›right LEFT:›Moves›cursor›left DOWN:›Moves›cursor›down› OK:›Selects›the›function› The›IR›sensor›is›located›in›the›lower›right›side›of›the›screen. Below›the›monitor›there›is›a›panel›to›configure›the›monitor.›Press›the›Up›/›Down›buttons›to›change›the›functions.› Press›the›OK›button›to›select›a›function.› Change›the›parameter›using›the›Up›/›Down›keys›and›press›again›OK›to›save›changes. AHnet ID:›Selects›the›number›AHnet›ID›to›RS422›to›control›the›monitor›externally Input select:›Selects›the›input›source›signal›(DVIA,›DVI1›or›DVI2).›No›function›on›this›model Brightness:›Configuration›of›the›monitor›brightness›level Contrast:›Configuration›of›the›monitor›contrast›level Backlight:›Configuration›of›the›monitor›backlight›level Status information:›Service›status›details... - Page 10 User manual Controls Controls There›are›two›buttons›to›control›the›up›and›down›monitor›function›placed›on›the›cover›plate. 1.› Retracting› the› monitor:› Be› aware› that› no› objects› nor› parts› of› the› body› are› located› between› the› frame› display› and› the› mechanism.›Press›the› › button›and›the›display›will›then›retract.›The›monitor›has›two›different›speeds. 2.› Raising›the›monitor:›Be›aware›that›no›objects›nor›parts›of›the›body›are›placed›on›the›surface›of›the›top›cover›plate,›which› could›obstruct›the›rising›of›the›display.›Press›the› › button›and›the›display›will›rise›out.›The›monitor›has›two›different›speeds.
-
Page 11: Osd Menu
User manual OSD Menu OSD Menu To›access›the›menu›system: › › With›the›OSD›off,›press›the›MENU›button›to›activate›the›main›OSD›menu › › Press›the›Up/Down›button›to›move›from›one›function›to›another.›Please›refer›to›the›sections›below›to›view›a›complete› list›of›all›of›the›functions›available›for›the›monitor › › Press›OK›button›to›enable›the›item › › When›a›function›is›selected,›press›the›Left/Right›buttons›to›change›the›parameter›of›the›function Press›the›Menu›button›to›access›the›main›menu: PICTURE › › Picture›Mode:›Adjusts›the›mode›of›the›image › – Dynamic › – Standard › – Mild › – User:›Contrast,›Brightness,›Colour,›Sharpness,›Tint › › Colour›Temperature:›Adjusts›the›colour›of›the›image ›... -
Page 12: Input›Connections
User manual Input Connections Input Connectors 12V›D.C.:›Power›supply›input›connector.›XLR-4›connector: 1,2:›Ground 3,4:›12Vdc GPI:›Monitor›external›contact›close›control.›SubD9›female. 1.› GPI1›+ 2.› GPI1›– 3.› GPI2›+ 4.› GPI2›– 5.› GPI3›– 6.› GPI3›+ 7.› N.C. 8.› +12Vdc›(600mA›max.) 9.› Ground Use›GPI1›(1:12Vdc,›2:›Ground)›to›open›the›monitor. Use›GPI3›(6:12Vdc,›5:›Ground)›to›close›the›monitor. Termination:›Activate›(ON)›the›termination›only›in›the›last›monitor›of›the›RS422›bus. AHnet:›RJ45›CAT5›connector›for›addressable›RS422›control.›There›is›a›loop›through›connector›to›use›as› › RS422›output›signal.› Up›to›30›monitors›can›be›connected›to›the›same›RS422›bus. SERVICE:› › Used›for›firmware›upgrade. - Page 13 User manual Input Connections DVI›1/DVI›A:›DVI-I›input›signal.›Connect›a›DVI›(digital)›input›signal›and›select›DVI›1›on›the›OSD›monitor›menu.›Use›a›DVI›to›VGA› adapter›to›connect›an›ARGB›(analogue)›input›signal›and›select›DVI-A›in›the›OSD›monitor›menu. DVI›2:›DVI-D›input›signal.›Connect›a›DVI›(digital)›input›signal›and›select›DVI›2›in›the›OSD›monitor›menu. Use›high›quality›DVI›cables›with›2m›maximum›length. Connect only RS422 signals to RS422 connectors. Be careful: do not connect network cables or PoE signals, it would damage the monitor seriously.
-
Page 14: Ahnet›Protocol
User manual AHnet Protocol AHnet Protocol › › Communication›type›:›RS422 › › Connection›type›:›RJ45 › › Wiring›type›:›CAT-5 › › Speed›and›configuration›: › – Baud›Rate›=›38400 › – Data›Bits›=›8 › – Parity›=›None › – Stop›Bits›=›1 WIRING›DIAGRAM 1.› Data›TX+ 2.› Data›TX- 3.› Data›RX+ 4.› NC 5.› NC 6.›... - Page 15 User manual AHnet Protocol Monitor›Commands: XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›BUS. CB1:›Response›in›8›bites›of›the›monitor›status CB2:›Response›in›8›bites›of›the›monitor›status CB1:...
- Page 16 User manual AHnet Protocol CB2: Image›Commands: XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›BUS. ZZ: Level›of›the›selected›function›(00-99›Dec) XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›BUS. ZZ: Level›of›the›selected›function›(00-99›Dec) To›send›an›order›to›all›the›monitors,›you›must›use›the›address: › 249›Dec.›(Byte›1)› › › › › › › › › › › › F9›Hex.›(Byte1) In›this›case,›the›units›will›not›respond.
-
Page 17: Input Resolutions
User manual Input Resolutions Input Resolutions... -
Page 18: Disposal›Information
User manual Disposal Information INFORMATION ON DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENTS WASTE This›symbol›on›the›products›and/or›accompanying›documents›means›that›used› electrical› and› electronic› products› should› not› be› mixed› with› general› household› waste. For›proper›treatment,›recovery›and›recycling,›please›take›these›products›to›designated›collection›points,›where›they›will›be› accepted›on›a›free›of›charge›basis.›Alternatively,›in›some›countries›you›may›be›able›to›return›your›products›to›your›local›retailer› upon›the›purchase›of›an›equivalent›new›product. Disposing›of›this›product›correctly›will›help›to›save›valuable›resources›and›prevent›any›potential›negative›effects›on›human› health›and›the›environment›which›could›otherwise›arise›from›inappropriate›waste›handling.›Please›contact›your›local›authority› for›further›details›of›your›nearest›collection›point. In›accordance›with›national›legislation›penalties›may›be›applicable›for›incorrect›disposal›of›this›waste. FOR BUSINESS USERS IN THE EUROPEAN UNION If›you›wish›to›discard›electrical›and›electronic›equipment,›please›contact›your›dealer›or›supplier›for›further›information. -
Page 19: Warranty
User manual Warranty ALBIRAL DISPLAY SOLUTIONS S.L. WARRANTY Valid from January 2016 ARTHUR›HOLM›/›ALBIRAL›VERTICAL›RETRACABLE›MONITORS›WARRANTY›TERMS: LIMITED›5-YEAR›WARRANTY›ENGINE›AND›MECHANICAL›LIFTING›PARTS The›engine›and›mechanical›lifting›parts›and›any›of›their›parts›other›than›those›covered›by›either›the›separate›warranties›below› or›those›subject›to›normal›wear›and›tear›are›guaranteed›to›be›free›from›manufacturing›defects›for›a›period›of›5›years›from›the› date›of›purchase.›If›any›manufacturing›defect›appears›in›the›engine›and›mechanical›lifting›parts›or›in›their›parts›other›than›those› parts›covered›below›or›those›subject›to›normal›wear›and›tear›within›5›years›of›purchase. LIMITED›2-YEAR›WARRANTY LCD›PANEL,›LCD›PANEL›INVERTER,›LCD›CONTROLER›AND›POWER›SUPPLY› The›electric›parts›of›this›Arthur›Holm›product›are›guaranteed›to›be›free›from›manufacturing›defects›for›a›period›of›2›years›from› the›date›of›purchase.› GENERAL›WARRANTY›TERMS a)› Parts:› During›the›warranty›period›mentioned›above›(LIMITED›5-YEAR›WARRANTY:›ENGINE›AND›MECHANICAL›LIFTING›PARTS› and› LIMITED› 2-YEAR› WARRANTY:› LCD› PANEL,› LCD› PANEL› INVERTER,› LCD› CONTROLER› AND› POWER› SUPPLY),› the› replacement›... - Page 20 Our Product Patents › MU 1996 ES00 › MU 16997 ES00 › MU 17180 ES00 › MU 17301 ES00 › MU 17322 ES00 › MU 17376 ES00 › MU 1741 ES00 › MU 17445 ES00 › P 248121 DEEP › P 24821 ESEP ›...
