Group Tune

Assign a tuning group to a channel.

Group Tune Setup

Tuning groups allow the user to set up a list of frequen-
cies, allowing for easy tracking of frequency tuning in
the transmitters.
• Four tuning groups are available, U, V, W, X.
• For each group, choose channel and frequency,
and choose to enable or disable the frequency.
• Each group can store up to 32 frequencies.
Use MENU/SEL to set and move cursor and the UP
and DOWN arrows to change values.
When a tuning group is assigned, the frequency control
is limited to the frequencies contained in the tuning
group. It also limits the available frequencies in the
frequency coordination process.
