Quick Start Guide
00825-0100-4102, Rev DD
February 2019
Rosemount
2051 Pressure Transmitter
and Rosemount 2051CF DP Flowmeters
®
with WirelessHART
Protocol

Advertisement

loading

Summary of Contents for Emerson Rosemount 2051CF

  • Page 1 Quick Start Guide 00825-0100-4102, Rev DD February 2019 ™ Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters ® with WirelessHART Protocol...
  • Page 2: Table Of Contents

    February 2019 Contents Wireless considerations......... 3 Trim the transmitter........13 Mount the transmitter........4 Verify transmitter configuration....15 Housing rotation..........11 Troubleshooting.......... 18 Connect the power module......12 Product Certifications........19 Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 3: Wireless Considerations

    Gateway, beginning with the closest. This will result in a simpler and faster network installation. Enable active advertising on the Gateway to ensure new devices join the network faster. For more information, see the Emerson Smart Wireless Gateway Reference Manual. Connecting the transmitter with a Field Communicator In order for the Field Communicator to interface with the Rosemount 2051 Wireless, the power module must be connected.
  • Page 4: Mount The Transmitter

    3. Mount the transmitter so the drain/vent valves are oriented upward. Gas applications Procedure 1. Place taps in the top or side of the line. 2. Mount beside or above the taps. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 5 February 2019 Quick Start Guide Steam applications Procedure 1. Place taps to the side of the line. 2. Mount beside or below the taps. 3. Fill impulse lines with water. Example Figure 2-1: Panel and Pipe Mounting Panel mount Pipe mount Coplanar flange Traditional flange Quick Start Guide...
  • Page 6 Use only ™ bolts supplied with the transmitter or sold by Emerson as spare parts. Figure illustrates common transmitter assemblies with the bolt length required for proper transmitter assembly. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 7 2-1. If bolt material is not shown in Table 2-1, contact a local Emerson Process Management representative for more information. Carbon steel bolts do not require lubrication and the stainless steel bolts are coated with a lubricant to ease installation. However, no additional lubricant should be applied when installing either type of bolt.
  • Page 8 O-ring grooves. Only use the O-ring that is designed for its specific flange adapter, as shown below. When compressed, PTFE O-rings tend to cold flow, which aids in their sealing capabilities. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 9 February 2019 Quick Start Guide Figure 2-3: O-rings A. Flange adapter B. O-ring C. PFTE based D. Elastomer Note You should replace PTFE O-rings if you remove the flange adapter. Environmental seal for housing Thread sealing (PTFE) tape or paste on male threads of conduit is required to ®...
  • Page 10 Keep the vent path free of any obstruction, including but not limited to paint, dust, and lubrication by mounting the transmitter so fluids can drain away. Figure 2-4: In-line Gage Low Side Pressure Port A. Pressure port location Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 11: Housing Rotation

    February 2019 Quick Start Guide Housing rotation To improve field access to wiring or to better view the optional LCD display: Figure 3-1: Housing Rotation A. Housing Rotation Set Screw (5/64-inch) Procedure 1. Loosen the housing rotation set screw using a 5/64 -in. hex wrench. 2.
  • Page 12: Connect The Power Module

    Connect the power module Procedure 1. Remove the power module cover. 2. Connect the green power module (see Figure 4-1). Example Figure 4-1: Power Module A. Power module Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 13: Trim The Transmitter

    February 2019 Quick Start Guide Trim the transmitter Devices are calibrated by the factory. Once installed, it is recommended to perform a zero trim on gage and differential pressure transmitters to eliminate error due to mounting position or static pressure effects. A zero trim can be performed using either a Field Communicator or configuration buttons.
  • Page 14 Figure 5-1: Digital Zero Button A. Digital zero button Note A zero trim can also be completed using AMS Wireless Configurator once the device has joined the network. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 15: Verify Transmitter Configuration

    February 2019 Quick Start Guide Verify transmitter configuration Operation can be verified in four locations: • At the device via the Local display (LCD display) • By using the Field Communicator • Via the Smart Wireless Gateway’s integrated web interface •...
  • Page 16 This page will show whether the device has joined the network and if it is communicating properly. Note It may take several minutes for the device to join the network. See Smart Wireless Gateway Quick Start Guide for more information. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 17 February 2019 Quick Start Guide Figure 6-1: Gateway Network Settings Verifying configuration using AMS Wireless Configurator When the device has joined the network, it will appear in the Wireless Configurator as shown in Figure 6-2. Figure 6-2: Wireless Configurator Network Setup Quick Start Guide...
  • Page 18: Troubleshooting

    ID and join key may be changed in the wireless device by using the following Fast Key sequence. See the Rosemount 2051 Wireless Reference Manual further troubleshooting. From the Home screen, enter the Fast Key sequence. Device Dashboard Fast Keys 3, 5 Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 19: Product Certifications

    RF spectrum. Nearly every country requires this type of product certification. Emerson is working with governmental agencies around the world to supply fully compliant products and remove the risk of violating country directives or laws governing wireless device usage.
  • Page 20 Special Conditions for Safe Use (X): 1. The plastic enclosure may constitute a potential electrostatic ignition risk and must not be rubbed or cleaned with a dry cloth. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 21 February 2019 Quick Start Guide 2. The Model 701PGNKF Power Module may be replaced in a hazardous area. The power module has a surface resistivity greater than 1 GΩ and must be properly installed in the wireless device enclosure. Care must be taken during transportation to and from the point of installation to prevent electrostatic charge build-up.
  • Page 22 IP Korea Intrinsic Safety Certificate: 13-KB4BO-0220X Markings: Ex ia IIC T4 (–40 °C ≤ T ≤ +70 °C) Special Conditions for Safe Use (X): 1. See certificate for special conditions. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 23 February 2019 Quick Start Guide Rosemount 2051 Wireless Declaration of Conformity EU Declaration of Conformity No: RMD 1087 Rev. I Rosemount, Inc. 8200 Market Boulevard Chanhassen, MN 55317-9685 declare under our sole responsibility that the product, Rosemount 2051/3051 Wireless Pressure Transmitters manufactured by, Rosemount, Inc.
  • Page 24 Sound Engineering Practice Transmitter Attachments: Diaphragm Seal, Process Flange, or Manifold Sound Engineering Practice Rosemount 2051CFx/3051CFx DP Flowmeters Refer to Declaration of Conformity DSI1000 Page 2 of 3 Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 25 February 2019 Quick Start Guide EU Declaration of Conformity No: RMD 1087 Rev. I ATEX Directive (2014/34/EU) Baseefa12ATEX0228X – Intrinsic Safety Certificate Equipment Group II, Category I G Ex ia IIC T4 Ga Harmonized Standards: EN 60079-0:2012 + A11:2013 EN 60079-11:2012 PED Notified Body DNV GL Business Assurance Italia S.r.l.
  • Page 26 GB/T 26572 X: Indicate that said hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement of GB/T 26572. Rosemount 2051 Pressure Transmitter and Rosemount 2051CF DP Flowmeters Quick Start Guide...
  • Page 27 February 2019 Quick Start Guide Quick Start Guide...
  • Page 28 The Emerson logo is a Facebook.com/Rosemount trademark and service mark of Emerson Electric Youtube.com/user/ Co. Rosemount is mark of one of the Emerson RosemountMeasurement family of companies. All other marks are the Google.com/+RosemountMeasurement property of their respective owners.
