E
E12X-SUB
Manual 5.2 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for d&b audiotechnik E Series

Summary of Contents for d&b audiotechnik E Series

  • Page 1 E12X-SUB Manual 5.2 en...
  • Page 2 General information E12X-SUB Manual Version: 5.2 en, 10/2018, D2073.EN .05 Copyright © 2018 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.

  • Page 3: Table Of Contents

    Contents Safety precautions.............. 4 1.1 Information regarding the use of loudspeakers......4 E12X-SUB loudspeaker............5 2.1 Product description..............5 2.2 Connections................5 2.3 Operation..................6 2.3.1 Controller settings..............7 2.3.2 Operation with E-PAC............. 7 2.4 Technical specifications.............. 7 Manufacturer's declarations........... 9 3.1 EU conformity of loudspeakers (CE symbol)......

  • Page 4: Safety Precautions

    Safety precautions 1.1 Information regarding the use of loudspeakers Potential risk of personal injury Never stand in the immediate vicinity of loudspeakers driven at a high level. Professional loudspeaker systems are capable of causing a sound pressure level detrimental to human health. Seemingly non-critical sound levels (from approx.

  • Page 5: E12X-Sub Loudspeaker

    E12X-SUB loudspeaker 2.1 Product description The E12X-SUB is a compact, high performance subwoofer for use with d&b E-Series loudspeakers. The cabinet houses a long excursion 12" neodymium driver in a bass-reflex design. It can be operated actively, driven by its own amplifier channel, without the need for any changes to the cabinet.

  • Page 6: Operation

    Note: When the D12 is operated in "Mix TOP/SUB mode", the SenseDrive function is only available at the output B connector. WR option (Weather Resistance) A number of d&b loudspeakers are available in special options suitable for different types of installed applications and environmental conditions.

  • Page 7: Controller Settings

    Within applicable d&b amplifiers, the controller setup is available in Dual Channel or Mix TOP/SUB mode. Passive operation Application Setup Combination per channel E12X-SUB E8-X with E8 In Dual Channel mode, the "X" setup can be selected to drive the cabinet in combination with the E8 loudspeaker on the same channel.
  • Page 8 E12X-SUB loudspeaker Nominal impedance 8 ohms Power handling capacity (RMS/peak 10 ms) 300/1600 W Components 1 x 12" driver Passive crossover network Connections 2 x NLT4 F/M optional: 2 x EP5 SC option: 2 x NL4 M WR option: Faston type connector (2 x 6.3mm) Pin assignments NLT4 F/M and NL4 M: 2+ / 2–...

  • Page 9: Manufacturer's Declarations

    Manufacturer's declarations 3.1 EU conformity of loudspeakers (CE symbol) This declaration applies to: d&b E12X-SUB loudspeaker, Z0210 manufactured by d&b audiotechnik GmbH. All production versions of these types are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
  • Page 11 www.dbaudio.com...
