  • Page 1 C4-SUB Manual (3.0E)
  • Page 2 WARNING! Dangerous voltage! General Information C4-SUB Manual Version 3.0E, 10/2003, D2075.E.03 © by d&b audiotechnik AG 2003; all rights reserved. The information contained in this manual has been carefully checked for accuracy, at the time of going to press, however no guarantee is given with respect to the correctness.

  • Page 3: Safety Precautions

    (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. C4-SUB Manual (3.0E) Safety instructions C4-SUB Manual (3.0E)
  • Page 4 Connections The C4-SUB cabinet is fitted with a pair of EP5 connectors. All pins n.c. of both connectors are wired in parallel. The C4-SUB uses the pin assignments 3/4 and 5 (Pin 5: SenseDrive - D12 only and in conjunction with 5-wire cables).
  • Page 5 +B2 circuit When C4-SUB cabinets are used with additional B2 subwoofers (INFRA mode) the C4-SUB controller can be set to +B2 mode. This introduces a relatively narrow band signal attenuation around 50 Hz, which raises the lower frequency limit of the C4-SUB to around 60 Hz.

  • Page 6: Technical Specifications

    Pin assignments ............3/4 and 5 (Pin 5: SenseDrive - D12) optional.........................2 x NL4 Pin assignments ......................2+ / 2– Weight .......................48 kg (106 lb) C4-SUB frequency response C4-SUB cabinet dimensions in mm [inch] C4-SUB Manual (3.0E) Page 6 of 8...
  • Page 7 EU conformity of loudspeakers This declaration applies to loudspeakers manufactured by d&b audiotechnik AG and includes the types listed in the table below: − C4-SUB Z2255 All production versions of these types are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
  • Page 8 C4-SUB Manual (3.0E) Page 8 of 8 d&b audiotechnik AG, Eugen-Adolff-Str. 134, D-71522 Backnang, Germany, Phone +49-7191-9669-0, Fax +49-7191-95 00 00...
