Summary of Contents for d&b audiotechnik Bi8-SUB

  • Page 1 Bi8-SUB Manual 1.1 en...
  • Page 2 General information Bi8-SUB Manual Version: 1.1 en, 03/2019, D2728.EN .01 Copyright © 2019 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.

  • Page 3: Table Of Contents

    Bi8-SUB loudspeaker............5 2.1 Product description..............5 2.2 Connections................5 2.3 Operation..................7 2.3.1 Controller settings..............8 2.4 Technical specifications.............. 8 Manufacturer's declarations........... 9 3.1 EU conformity of loudspeakers (CE symbol)......9 3.1.1 WEEE Declaration (Disposal)..........9 d&b Bi8-SUB Manual 1.1 en...

  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Bi8-SUB Manual 1.1 en...

  • Page 5: Bi8-Sub Loudspeaker

    Fixed cable connection The Bi8-SUB loudspeaker is supplied with a cover plate [1] and a rubber grommet feed through [2]. For indoor operation, these items can be used to hide the connector panel, if required. For unprotected outdoor operation, the connector panel must be covered, i.e.
  • Page 6 The cover plate is equipped with two knockout openings to allow daisy chaining of the loudspeaker. To use the NL4 connection, proceed in the same manner as described in the previous section. NL4 cable connection with cover plate [1] d&b Bi8-SUB Manual 1.1 en...

  • Page 7: Operation

    Only operate d&b loudspeakers with a correctly configured d&b amplifier, otherwise there is a risk of damaging the loudspeaker components. Applicable d&b amplifiers: 10D/30D/D20/D80/D6. Amplifier output mode(s): Dual Channel or Mix TOP/SUB Application Setup Cabinets per channel Bi8-SUB B8-SUB d&b Bi8-SUB Manual 1.1 en...

  • Page 8: Controller Settings

    For acoustic adjustment the 100 Hz mode can be selected. 100 Hz mode It can be used when actively driven Bi8-SUB cabinets are used to supplement TOP cabinets operated in full range mode, for example in a distributed sound system. The 100 Hz mode can also be used to compensate for the effect of close coupling between the Bi8-SUB and TOP cabinets operated in CUT mode.

  • Page 9: Manufacturer's Declarations

    Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Bi8-SUB Manual 1.1 en...
  • Page 11 www.dbaudio.com...
