4. HOW TO INSTALL OPTIONAL
EQUIPMENT
The optional waterproofing kits OP16-58 and OP16-61 are used to protect the con-
nectors on the communication unit from water splash. Note that these optional kits
should be used as a couple.
4.1 IPX2 Kit OP16-58 (cables)/Waterproofing Kit
OP16-60 (for IC-318)
OP16-58
Connect the waterproofed D-sub cables to the rear of the communication unit, instead
of the standard supply cable.
Name
Cable Assy.
OP16-60
The IC-318 should be installed on a desktop. To ensure the waterproof rating is main-
tained, use the optional waterproofing kit OP16-60. If a floor installation is required,
make sure the area is not subject to water splash, rain or other water ingress.
Name
Cover gasket
Grommet
OP16-58 (Code No.: 001-180-070)
Type Code No.
H230817-1 001-176-552-10
H230817-2 000-176-553-10
XM-FD-361 000-176-551-10
OP16-60 (Code No.: 001-180-090)
Type
16-023-5502
16-023-5503
Qty
1 Not used.
1 Not used.
1 For connection with IC-318
Code No.
100-373-530-10
100-373-541-10
Remarks
Qty
1
1
4-1
