3. INITIAL SETTINGS
4. Press the function key F8 to show the [Setup] menu.
File Edit
1. System Setup
2. Editor Setup
3. Terminal Setup
4. EGC Setup
5. Auto Mode Setup
6. E-Mail Setup
7. Directories
8. Configuration
5. Press the 1 key to display the [System Setup] menu.
6. Confirm that the [IMN] is selected, and then press the Enter key.
An input box appears.
7. Key in your IMN.
8. Press the Enter key.
9. Press the Esc key to erase the input box.
10. Press the Enter key.
11. Press the Esc key.
To clear the IMN, select IMN, then press I, M, N while pressing the Alt key. Repeat
step 6 to step 8 to input the correct IMN. When using the FELCOM19 for VMS (Vessel
Monitoring System), DNID (Data Network ID) has to be downloaded via the LES (Land
Earth Station). This arrangement is normally done by authority of VMS.
3.4

How to Set up the AMS/BAM

Do the following to connect the AMS (Alert Management System).
1. Press the F8 and 1 keys to show the [System Setup] menu.
2. Press
3. Enter the [Enter JOB No.:], then press the Enter key.
4. Enter the [PASSWORD:], then press the Enter key.
3-6
Transmit EGC Reports
Setup
Setup
System Setup
System Date & Time
IMN
MES Operation Mode
Nav Port
LAN Port
Message Output Port
EGC Output Port
Network Setup
Command Window
to select [Command Window], and then press the Enter key.
Logs Options Setup Distress StopAlarm
01:53 12-01-31 (YY-MM-DD)
INMARSAT-C
OFF
ON
INT
INT
