4.
HOW TO INSTALL OPTIONAL
EQUIPMENT
The optional waterproofing kits OP16-58 and OP16-61 are used to protect the con-
nectors on the communication unit from water splash. Note that these optional kits
should be used as a couple.
4.1
IPX2 Kit OP16-58 (cables)/Waterproofing Kit
OP16-60 (for IC-318)
OP16-58
Connect the waterproofed D-sub cables to the rear of the communication unit, instead
of the standard supply cable.
Name
Cable Assy.
OP16-60
To mount the IC-318 on a bulkhead, use the waterproofing kit to keep water splash
out of the unit. When the OP16-58 is used, replace the cable from the IC-318 with the
XM-FD-361 as shown on next page.
Name
Cover gasket
Grommet
OP16-58 (Code No.: 001-180-070)
Type
Code No.
H230817-1
001-176-552-10
H230817-2
000-176-553-10
XM-FD-361
000-176-551-10
OP16-60 (Code No.: 001-180-090)
Type
16-023-5502
16-023-5503
Qty
1
Not used.
1
Not used.
1
For connection with IC-318
Code No.
100-373-530-10
100-373-540-10
Remarks
Qty
1
1
4-1
