- Page 1 Customer Sevice Technical Info. Parts & Accessories AH7-X30P SERIES Promotions www.facebook.com /AntraHelmets Auto-Darkening Welding Helmet User Manual Made in china 2017...
-
Page 2: Important Safety Instructions
Antra AH7-X30P Series ARC RAYS can burn eyes ! Auto-Darkening Welding Helmet Never look at arc welding without proper eye protection. Arc rays from the welding process produce intense visible and invisible (ultraviolet and infrared) 2017 rays that can burn eyes and Skin, Hot sparks fly off from the weld and can burn eyes and skin. -
Page 3: Technical Specifications
GENERAL INFORMATION MARKING EXPLAINED AH7-X30P Series Auto-Darkening Welding Helmet does not protect against severe impact hazards, such as fractured grinding wheels or abrasive discs，explosive devices or corrosive liquids． Machine guards or eye splash protection must be used when these hazards are present．... -
Page 4: Operation
1.OPERATION When stored in extremely cold temperature, the helmet should be warmed up to • ADJUST THE WELDING HELMET ACCORDING ambient temperature before welding. TO YOUR INDIVIDUAL REQUIREMENTS. Inspect all parts for signs of wear or damage. Any scratched or cracked parts should be •... -
Page 5: Parameter Adjustment
ON/OFF The solar unit automatically switches ON when 3.SENSITIVITY CONTROL exposed to light. Press the Mode button(7), until the triangle mode indicator is on Sensitivity, the LED Press any button to check if the lens is working screen(6) now shows the current sensitivity setting. Press UP arrow (8) and DOWN arrow to properly and to begin Mode and Info adjustments. -
Page 6: Replacement Of Batteries
REPLACEMENT OF INNER COVER LENS REPLACEMENT OF EXTERIOR COVER Detach the auto darkening filter from the helmet LENS shield (Refer to REPLACEMENT OF WELDING FILTER). Pull up the two lock lug on the bottom of the (Fig.7) (Fig.11). filter (Fig.7), the filter cartridge will pop loose Lift up one edge of the inner cover lens and pull from the shield. -
Page 7: Troubleshooting
TROUBLE SHOOTING AUTO DARKENING FILTER DOES NOT DARKEN OR FLICKER - Check the lens cover for dirt and spatter that may be blocking the arc sensors. - The sensors are dirty, wipe them clean with a soft lint-free cloth. - Check the sensitivity setting recommendations and increase the sensitivity if possible. Feed the top edge of the cartridge back to the - Increasing lens delay 0.1-0.3 second may also reduce flickering. -
Page 8: Warranty
WARRANTY We warrants to the purchaser that the product will be free from defects in material and workmanship for the period of one year from the date of purchase. Our sole obligation under this warranty is limited to replacement or repairs. This warranty does not cover product malfunctions or damages, which result from the product being tampered, misused or abused.
