- Page 1 Customer Service Parts & Accessories www.AntecTrade.com www.facebook.com/AntraHelmets Digital-Pro SERIES Toll-Free:1-888-450-6788 North America Outside of USA & Canada: +1-905-415-3487 E-mail:info@antectrade.com Auto-Darkening Welding Helmet User Manual Made in china V5.0...
-
Page 2: Important Safety Instructions
Digital-Pro SERIES ARC RAYS can burn eyes ! Never look at arc welding without proper eye protection. Arc rays from the welding process produce intense visible and invisible (ultraviolet and infrared) Auto-Darkening Welding Helmet 2023 rays that can burn eyes and skin. -
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS FLYING METAL can injure eyes ! Model • Welding, chipping, wire brushing, and grinding causes sparks and flying metal. As welds ADF Model cool, they can throw off slag. Viewing Area 100mm x 82mm/3.94" x 3.23" • Wear ANSI approved safety glasses with side shields under your welding helmet. Cartridge Size 100mm x 114mm x 7mm/5.24"... -
Page 4: Operation
1.OPERATION ADJUST THE WELDING HELMET ACCORDING TO YOUR INDIVIDUAL REQUIREMENTS. When stored in extremely cold temperature, the helmet should be warmed up to • The headgear should be adjusted both in circumference and height. ambient temperature before welding. Use the ratcheting knob on the headgear to adjust width. Inspect all parts for signs of wear or damage. -
Page 5: Settings Adjustment
(1) WELD MODE If the helmet is stored in at a place where triggers the lens to dark, manually switch off the helmet to save power. The lens will draw little to no battery power when it is standby, provided Press button to adjust shade level from 9 to 14 with a step of 0.5. -
Page 6: Delay Control
(5) DELAY CONTROL alternate display The delay mode adjusts how quickly the lens goes from dark state back to light state. Press button to adjust delay time from 0.1-0.9s and A. When delay displays “A”,(Fig the lens will provide shade related delay time on Auto Delay Option. Use the longer delay setting for higher amperage welds or where the weld pool remains intense after the arc is extinguished. -
Page 7: Battery Display
REPLACEMENT OF EXTERIOR LENS COVER PLATE DO NOT use the helmet without exterior and interior lens cover plate installed ， or the lens will be damaged ， and the protection will be compromised. Pull up the two lock lugs on the bottom of the lens (Fig.14a), the lens cartridge will pop loose from the shield. - Page 8 REPLACEMENT OF AUTO-DARKENING WELDING LENS Pull up the two lock lugs on the bottom of the lens (Fig.17a), the lens cartridge will pop loose from the shield. Detach the cartridge from the shield. Hold the cartridge with both hands, with solar cell side up, lift top edge of the cartridge using thumbs to loose the lens from the cartridge.
-
Page 9: Troubleshooting
7.INSPECTION 1. Carefully inspect your Auto-Darkening Welding lens regularly. If the described malfunctions cannot be solved, stop using the helmet immediately and contact 2. Cracked, pitted or scratched lens glass or lens cover plate reduced vision will seriously the nearest distributor. impair protection.
