- Page 1 Customer Service Parts & Accessories WWW.AntecTrade.com WWW.facebook.com/AntraHelmets Digital-Pro SERIES Toll-Free:1-888-450-6788 North America Outside of USA & Canada: +1-905-415-3487 DP5A E-mail:info@antectrade.com Auto-Darkening Welding Helmet User Manual Made in china V1.0...
-
Page 2: Important Safety Instructions
Digital-Pro SERIES ARC RAYS can burn eyes ! DP5A Never look at arc welding without proper eye protection. Arc rays from the Auto-Darkening Welding Helmet welding process produce intense visible and invisible (ultraviolet and infrared) rays that can burn eyes and skin. -
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS FLYING METAL can injure eyes ! Model DP5A • Welding, chipping, wire brushing, and grinding causes sparks and flying metal. As welds ADF Model DP5A cool, they can throw off slag. Viewing Area 98mm x 53mm/3.86" x 2.09" •... -
Page 4: Operation
1.OPERATION ADJUST THE WELDING HELMET ACCORDING TO YOUR INDIVIDUAL REQUIREMENTS. When stored in extremely cold temperature, the helmet should be warmed up to • ambient temperature before welding. The headgear should be adjusted both in circumference and height. Inspect all parts for signs of wear or damage. Any scratched or cracked parts should be •... -
Page 5: Sensitivity Control
4.DELAY CONTROL SETTINGS ADJUSTMENT The delay settings allow the user to adjust the recovery delay time (going from dark to Press button to choose mode: weld /cut light)manually according to the requirements of the welding process to reduce eye stain. A longer delay may help protect the eyes from the bright light of a large, hot weld pits. -
Page 6: Recommended Settings
RECOMMENDED SETTINGS 6.AUTO SHADE In this mode, stitch welding is not recommended. Shade 8 Shade 9 Shade 10 Shade 11 Shade 12 Shade 13 Shade 14 Press button to choose Auto Shade Mode(Fig.9). Shade 11 Shade 12 Shade 13 Shade 14 Shade 15 Shade 11 Shade 12... - Page 7 REPLACEMENT OF INTERIOR LENS COVER PLATE NEVER put used batteries into house hold waste. Detach the auto darkening lens from the helmet shield (Refer to REPLACEMENT OF WELD- Please always have used batteries recycled properly. ING LENS). Lift up one edge of the interior lens cover plate and pull the lens cover plate away from the lens REPLACEMENT OF EXTERIOR LENS COVER PLATE (Fig.14a).
-
Page 8: Warranty
THE LENS STAYS DARK AFTER THE WELD ARC IS EXTINGUISHED, OR THE AUTO-LENS STAYS DARK WHEN NO ARC IS PRESENT. - Fine-tune the sensitivity setting in small increments. In extreme light conditions, it may be necessary to reduce the surrounding light levels. SLOW SWITCHING - The operating temperature is too low, don’t use at temperatures of below -5 ℃...
