FOX3-2G/3G/4G/-4G-PROMOTION-KIT Getting Started
Article name QTY Description
FOX3-2G/3G/4G (BOX)
FOX3 unit 1
Battery 1
PREMIUM-FEATURES -
SIM-Card 1
ANT-11 /
ANT-12 / 1
ANT-14 /
Instruction sheet 1
Info-Sheet 1
Support -
FOX3-2G/3G/4G-CONTROL-BOX
Control-Box 1
USB to SERIAL 1
CA27 1
CA31 1
CA69 1
CA76 1
CA123 1
POWER-SUPPLY-BOX
Power Suppy 1
Table 1: The list of items included in the PROMOTION-KIT.
2.2

Related documents

In addition to this document, the following files comprise the full set of FOX3-2G/3G/4G product manuals
and can be downloaded from the FALCOM web site (protected area). Downloading documents from the
FALCOM website:
1. Open your installed browser and enter
2. Log-in using the logging data (Username & Password) available in the Info Sheet delivered with the
PROMOTION-KIT
3. Go to "Support" and select
4. This will list the supporting documents for all FALCOM AVL devices. Please, download just the
documents listed in the table below.
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
FOX3 or FOX3-3G unit, pre-configured with access to the FALCOM D2Sphere server. The device is
placed in the IGN-Sleep mode prior to being shipped from the factory and can be woken up via
IGN-Switch or a high signal on IGN-pin.
1000 mAh rechargeable battery (already inserted and connected to the FOX3-2G/3G/4G/-4G)
All PREMIUM-FEATURES are activated by the factory. For details how to use them refer to the
corresponding Application Notes listed in chapter 2.2
Prepaid SIM card. Service fee includes 10MB of data transfer and 3 months access to the FALCOM
D2Sphere server for evaluation purposes.
Depending on which Promotion Kit you ordered, one of the following external antennas will be
part of your kit:
ANT-11 : Quad Band GSM+GPS combination antenna for FOX3 only.
ANT-12 : Penta Band GSM/WCDMA combination antenna for FOX3-3G.
ANT-14 : GSM/UMTS/WCDMA/LTE and GNSS combined antennas for FOX3-4G.
More details: http://www.falcom.de/products/accessories/antennas/
Necessary information how to get started with FALCOM AVL devices.
Contains log-in data to access the online documentation on the FALCOM website and FALCOM
D2Sphere server for evaluation purposes.
8 hours free technical support.
To test the functions of the FOX3-2G/3G/4G device and allows connection to your PC for
evaluation purposes.
This cable allows a serial connection through the USB port of the PC to the serial port of the control
box.
Main port service and power connection cable
Installation cable for FOX3-2G/3G/4G with interface to the RFID-Reader or JAZZ2. This cable allows
to install your FOX3-2G/3G/4G to the vehicle.
This cable allows testing of the available pins on the accessory port of the FOX3-2G/3G/4G (e.g. 1-
Wire bus). It has a 4pin connector for connecting to a RFID-Reader or JAZZ2 device.
Accessory port service cable with 2x3pin connector to DB9 female socket with a length of 1.0 m
2x4pin connector to OBDII cable with separated IGN-wire. Cable length of 1.5 m
Type FW7238/12 incl. UK/US/AU/EU adaptor
https://www.falcom.de/distributor-login/?origin=4
"AVL (FOX3, STEPPIII,.....)" from the "Documentation" selection box
Version 1.0.7
Page 6 of 25
