FOX3-2G/3G/4G/-4G-PROMOTION-KIT Getting Started
Functions Configuration alarms and their descriptions.
detached from that services but it still has a valid GSM operator, the green LED (IO12) will blink fast.
$PFAL,CNF.Set,AL23=TCP.Client.eConnected:IO12.Set=high
$PFAL,CNF.Set,AL24=TCP.Client.eDisconnected&GSM.sOpValid:IO12.Set=cyclic,400,400
AL23, 24: Once the device is connected to TCP server, the green LED (IO12) goes ON and when it is
disconnects from that server but it still has a valid GSM operator, the green LED (IO12) will blink slower
than when it detaches from GPRS services.
Configuration $PFAL,CNF.Set,DEVICE.BAT.CHARGEMODE=eco
parameters
Starts charging if the voltage of the internal battery drops to less than 3.9V and terminates charging
when the battery is full-charged.
$PFAL,CNF.Set,DEVICE.BAT.MODE=auto
Automatically switching between external power and internal battery power source depending on the
power source currently available. External DC power supply has priority, if it is higher than 8 V.
$PFAL,CNF.Set,DEVICE.COMM.SERIAL0=cmd,7F
The serial port 0 is set into the command operation mode with protocols and events output enabled.
$PFAL,CNF.Set,DEVICE.COMM.TCP.CLIENT=cmd,60
The serial port 0 is set into the command operation mode without protocols and events output enabled
$PFAL,CNF.Set,DEVICE.GPS.AUTOCORRECT=on,5.0,58,50,10,50
Enables filtering of GPS auto correction to calculate a valid GPS fix using maximal allowed PDO of 5.0,
maximal speed limit of 58 m/s, maximal allowed distance error of 50, drop count incorrect position of 10
and maximal acceleration of 50 m/s.
$PFAL,CNF.Set,DEVICE.GPS.CFG=4
At least 4 satellites must be in use to consider a GPS fix as valid.
$PFAL,CNF.Set,DEVICE.GPS.HEADING=25
Heading tolerance is set to 25 degrees. Each time this angle is exceeded, the event
GPS.Nav.eChangeHeading occurs, and the driving direction resets to zero.
$PFAL,CNF.Set,DEVICE.GPS.TIMEOUT=1,30
Restarts the GPS receiver to do a new search for visible GPS satellites, if within this time no valid fix is
available.
$PFAL,CNF.Set,DEVICE.NAME=FOX3
Device name is defined to FOX3
$PFAL,CNF.Set,DEVICE.PFAL.SEND.FORMAT="$",CKSUM,"","$<end>"
The syntax of the PFAL messages is defined to start each line with the character '$', followed by the user
text and terminated by a NMEA compatible checksum and <CRLF>. The complete message(s) end(s) with
$<end>. These settings can be changed based on your server requirements.
$PFAL,CNF.Set,PPP.PASSWORD=blau
Required string (password) for the Chap and Pap authentication methods over PPPP to attach the device
into the GPRS network. This setting is provider-dependant.
$PFAL,CNF.Set,PPP.USERNAME=blau
Required string (username) for the Chap and Pap authentication methods over PPPP to attach the device
into the GPRS network. This setting is provider-dependant.
$PFAL,CNF.Set,GPRS.APN=Public4.m2minternet.com
APN (Access Point Name) name that your network operator has provided to you to connect the device to
the GPRS/Internet. This setting is operator or provider dependant.
