FOX3-2G/3G/4G/-4G-PROMOTION-KIT Getting Started
4pin UCOM Connector
PURPLE
RxA_0
Input
BLACK
TxA_0
Output
RED
+IN
Input
BROWN
GND
-
Table 7:
The pin function and the colour codes of the CA69 is listed in table below:
COLOUR
NAME
Open end wires
PINK
1-Wire
BROWN
GND
PURPLE
RxA_1
BLACK
TxA_1
YELLOW
SCL
GREEN
SDA
4pin UCOM Connector
PURPLE
RxA_1
BLACK
TxA_1
RED
+IN
BROWN
GND
Table 8:
The pinout of this cable CA76 is listed in table below:
2x3 MICROFIT
DB9 female
RX
RX
TX
TX
GND
GND
Table 9:
The pinout of this cable CA123 (OBDII 4Pin Cable) is listed in table below:
2x4 MICROFIT
OBDII connector
2
5
6
6
5
14
1
16
3
NC
Table 10:
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Serial Port 0 - Receive data
Serial Port 0 - Transmit data
Power supply input.
Ground.
PIN function of the CA31 cable
DIRECTION
DESCRIPTION
1-Wire master interface for Driver ID,
Input /Output
temperature and humidity sensors.
-
Ground Reference.
Input
Serial Port 1 - Receive data.
Output
Serial Port 1- Transmit data
Output
I2C bus interface - Serial Clock line
Input /Output
I2C bus interface - Serial Data line
Input
Serial Port 1 - Receive data
Output
Serial Port 1- Transmit data
Input
Power supply input.
-
Ground.
Pinout of the CA69 cable
Pinout of the CA76 cable
Pinout of the CA123 cable
Version 1.0.7
V24, ±12 V
V24, ±12 V
=+IN
0V
LEVEL
V
= + 2.8 .. +5.0 V
OUT
0 V
V24, ±12 V
V24, ±12 V
-
-
V24, ±12 V
V24, ±12 V
V
= + 10.8 ... + 32.0 V
+IN
Imax ≤ 1.5 A
0V
Description
Receive data
Transmit data
Ground
Description
GND
CAN_High
CAN_Low
V+
IGN as separate wire
Page 22 of 25
