FALCOM FOX3-2G Series Getting Started page 20

FOX3-2G/3G/4G/-4G-PROMOTION-KIT Getting Started
Functions Configuration alarms and their descriptions.
VTG protocol is deactivated
$PFAL,CNF.Set,TCP.CLIENT.CONNECT=1,5.35.253.3,4444
Enables the connection to the remote server and specifies the IP address and the Port number of the TCP
server to connect to.
$PFAL,CNF.Set,TCP.CLIENT.DNS.TIMEOUT=86400
The length of time (in seconds) to keep the DNS cache valid.
$PFAL,CNF.Set,TCP.CLIENT.LOGIN=1
Sends the login data automatically to the remote server after requesting the TCP server for establishing a
connection.
$PFAL,CNF.Set,TCP.CLIENT.PING=1,240000
Activates sending of pings and specifies the amount of time, in milliseconds, on which a ping will be sent
to the remote server.
$PFAL,CNF.Set,TCP.CLIENT.SENDMODE=2
Safe and non-volatile transmission mode.
$PFAL,CNF.Set,TCP.CLIENT.TIMEOUT=300000,30000
Period of time in milliseconds that the device will wait for a response and between two connection
attempts when TCP connection fails.
$PFAL,CNF.Set,GSM.PIN=1111
Enters/saves the PIN code of the SIM card inserted into the device..
$PFAL,GSM.Band=auto
The GSM band to be used by the device is set to 'auto'. The device registers to that frequency band
currently available. Refer to the PFAL command set for the supported settings.
Factory settings It consists of configuration settings preloaded at the factory during the manufacturing of FOX3 series
devices. The user has the possibility of personalizing this configuration and with the help of
$PFAL,Sys.Device.FactoryReset command it is possible to overwrite the User Settings with the Factory
Settings. After reseting the device to factory settings, the device must be configured in order to operate
referring to your application (see chapter for more details
Add-ons* The Promotion Kit is shipped with some sample functions. To extend its functionality, you can refer to the
setting file „AddOns.conf" and modify it according to your needs. Please contact support (see chapter 3.2)
for more details about the file „AddOns.conf".
eCodrive
Tampering
Waypoints
Tilting
1Wire
CAN-OBDII
CAN-FMS
HINT: The user text (in quotation marks " ") started with "sfal" indicates an event on our D2Sphere serve
supported on our server, use other text formats for your own server.
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
(This feature includes instant and results for driving activities and driver behaviors such as: TripStart /
TripStop / Harsh-Brake / Harsh-Acceleration / Harsh-Turn) - refer to the
Detection of GPS antenna (unplugged / plugged / cut) – Refer to the PFAL command set manual.
(define reference GPS points along a specific route where the vehicle should track. Alerts when
exiting/entering that route)
(> 45°) and crash detection (1 x Tilt alert every 15 sec.)
(iButton + Temp. Sensors)
Supported iButton: DS1402D-DR8+ Blue Dot Receptor iButton Reader Cable with DS1982 iButton and
DS1921 iButton (MAXIM).
Supported 1Wire Temp.Sensor: DS18(B)20 (MAXIM). Refer to the
(read out some of the supported OBDII raw values). Refer to the
(read out some of the supported FMS parameters). Refer to the
Version 1.0.7
Related documents
[6]
Related documents
[13]
Related documents
[4]
Related documents
[4]
.
This event text is only
Page 19 of 25
