bits
0111
1000
1001
1010
1011
1100
b
12
(or b
in CANopen®)
4
0
1
13.2.6 Logical outputs 3&4 assignment
Similar to the outputs 1&2 configuration parameter, see previous paragraph (replacing all references to output 1 by
output 3 and all references to output 2 by output 4).

13.2.7 Weight quantity per pulse on logical output

When a logical output is assigned to external totalizer, a pulse is generated every time the totalization increases a
multiple of a weight quantity per pulse on logical output. The maximum pulse frequency is 10 Hz and pulse duration
is fixed at 50ms. The output pulse is not rounded (i.e. the pulse is issued only once weight quantity per pulse on
logical output is strictly exceeded).
meaning
external totalizer
belt system running
batch in progress
batch result available
conveyor starting alarm
material TOR gate
negative logic
positive logic
User manual SCAIME:
note
Belt mode
Belt mode
Belt mode
Belt mode
Belt mode
Belt mode
output 2 logical
defines the output level when enabled
defines the output level when enabled
71/108
NU-soft-eNod4B-ETH-E-0716_236709-C.doc
