1 ENOD4 PRODUCT RANGE

1.1 General presentation

eNod4 is a high speed digital process transmitter with programmable functions and powerful signal processing
capabilities. eNod4 offers operating modes for advanced process control both static and dynamic.
Quick and accurate:
•
Analog to digital conversion rate up to 1920 meas/s with maximum scaled resolution of ±500 000 points.
•
Digital filtering and measurement scaling.
•
Measurement transmission up to 1 000 meas/s.
Easy to integrate into automated system:
•
USB, RS485 and CAN communication interfaces supporting ModBus RTU, CANopen® and PROFIBUS-DPV1
(depending on version) communication protocols.
•
Digital Inputs/Outputs for process control.
•
Setting of node number by rotary switches and communication baud rate by dip switches.
•
Integrated selectable network termination resistors.
•
Wiring by plug-in terminal blocs.

1.2 Versions

1.2.1 Communication protocol versions

•
Strain gauges load-cell conditioner with CANopen® and ModBus RTU communication.
•
Strain gauges load-cell conditioner with Profibus DP-V1 and ModBus RTU communication.
•
Strain gauges load-cell conditioner with Modbus TCP and ModBus RTU communication.
•
Strain gauges load-cell conditioner with EtherNet/IP and ModBus RTU communication.
•
Strain gauges load-cell conditioner with Profinet IO and ModBus RTU communication.
•
Strain gauges load-cell conditioner with EtherCAT and ModBus RTU communication.
EDS, GSD, ESI and GSDML configuration files for above protocols can be downloaded from our web site:
http://www.scaime.com

1.2.2 IO+ version

In conjunction with all communication protocol versions, eNod4 can supports an opto-insulated board fitted with:
•
2 additional digital inputs and 1 speed sensor dedicated input.
•
0-5V or 0-10V analog output voltage.
•
4-20mA, 0-24mA, 0-20mA or 4-20mA with alarm at 3.6mA analog output current.
